SPCT2-135/4 167586 EATON ELECTRIC Plug-in surge arresters, 4p, 135VAC, 4x20kA
SPCT2-135/4
167586
EATON - MOELLER
1 Pcs.
Automation > Surge protection device for power supply systems
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
SPCT2-135/4 167586 EATON ELECTRIC Plug-in surge arresters, 4p, 135VAC, 4x20kA are utilized in industrial and commercial electrical setups to protect installations against destructive transient overvoltages. These 4-pole plug-in units effectively divert high surge currents to ground, minimizing potential equipment failure across multi-phase networks. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- System configuration DC (EF009926): No
- System configuration IT (EF009927): No
- System configuration TN (EF009928): Yes
- System configuration TN-C (EF009929): No
- System configuration TN-C-S (EF009933): No
- System configuration TN-S (EF009930): No
- System configuration TT (EF009931): No
- System configuration other (EF009932): Yes
- Number of conductors (without earthing) (EF001148): 4
- Nominal discharge surge current (8/20) (EF004214): 20 kA
- Max. discharge surge current (8/20) (EF012274): 40 kA
- Nominal voltage AC (EF004220): 135 V
- Nominal voltage DC (EF004221): 0 V
- Max. continuous voltage AC (EF004198): 135 V
- Max. continuous voltage DC (EF004777): 0 V
- Max. PV-voltage (EF008795): 0 V
More info
▲General specifications
Delivery program
Technical data - electrical
Technical data - mechanical
Additional information
TN
