EATON - MOELLER SPCT2-135/2 SPCT2-135/2 167584 EATON ELECTRIC Plug-in surge arresters, 2p, 135VAC, 2x20kA View larger
Images are for illustrative purposes only. Please refer to data sheet for details

SPCT2-135/2 167584 EATON ELECTRIC Plug-in surge arresters, 2p, 135VAC, 2x20kA

SPCT2-135/2

167584

EATON - MOELLER

1 Pcs.

Plug-in surge arresters, 2p, 135VAC, 2x20kA SPCT2-135/2

Automation > Surge protection device for power supply systems
Modular Switchgear – Industrial

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

The SPCT2-135/2 from Eaton Moeller is a robust plug-in surge arrester configured to protect consumer systems from indirect lightning discharges and switching anomalies. Installers incorporate these devices into sub-distribution boards to shield delicate loads from destructive electrical transients. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Manufacturer: Eaton Moeller
  • Manufacturer part number: SPCT2-135/2
  • Catalogue code: 167584
  • Catalogue title: SPCT2-135/2 167584 EATON ELECTRIC Plug-in surge arresters, 2p, 135VAC, 2x20kA
  • Product description: Plug-in surge arresters, 2p, 135VAC, 2x20kA For protecting consumer systems against transient overvoltages caused by indirect lightning strikes and switching operations, test class II according to IEC 61643-1+A1, SPD-typ
  • Manufacturer summary: Plug-in surge arresters, 2p, 135VAC, 2x20kA SPCT2-135/2

More info

▲
Plug-in surge arresters, 2p, 135VAC, 2x20kA
For protecting consumer systems against transient overvoltages caused by indirect lightning strikes and switching operations, test class II according to IEC 61643-1+A1, SPD-type T2 according to EN 61643-11, SPC-S-HK auxiliary contact for remote signaling can be added, can be bussed with all Xtra Combinations switchgear caused by indirect lightning strikes and switching operations, test class II according to IEC 61643-1+A1, SPD-type T2 according to EN 61643-11, SPC-S-HK auxiliary contact for remote signaling can be added, can be bussed with all Xtra Combinations switchgear

Delivery program

Products
Surge arresters
Application field
Residential buildings
Utility buildings
Open areas

Technical data ETIM 7.0

Earthing, lightning and surge protection (EG000021) / Surge protection device for power supply systems (EC000941)
Electric engineering, automation, process control engineering / Protection installation, device (electric) / Surge protection device (inner lightning protection) / Surge protection device for power supply systems ([email protected] [ACN278011])
System configuration DC
No
System configuration IT
No
System configuration TN
Yes
System configuration TN-C
No
System configuration TN-C-S
No
System configuration TN-S
No
System configuration TT
No
System configuration other
Yes
Number of conductors (without earthing)
2
Nominal discharge surge current (8/20)
20 kA
Nominal voltage AC
135 V
Nominal voltage DC
0 V
Short-circuit breaking capacity (Isccr)
0 kA
Max. continuous voltage AC
135 V
Max. discharge surge current (8/20)
40 kA
Max. continuous voltage DC
0 V
Mounting method
DIN rail (top hat rail) 35 mm
Construction size
2 modular spacing
Max. PV-voltage
0 V
Voltage protection level
0.8 kV
Max. conductor cross section solid (solid, stranded)
25 mm²
Max. conductor cross section flexible (fine-strand)
35 mm²
Voltage protection level L-N
0 kV
Voltage protection level N-PE
0 kV
With remote signalling contact
No
Integrated backup fuse
No
Signalling at the device
Optic
Category type 2
Yes
Degree of protection (IP)
IP20
