EATON - MOELLER SPCT2-075/1 SPCT2-075/1 167578 EATON ELECTRIC Plug-in surge arresters, 1p, 75VAC, 20 kA View larger
Images are for illustrative purposes only. Please refer to data sheet for details

SPCT2-075/1 167578 EATON ELECTRIC Plug-in surge arresters, 1p, 75VAC, 20 kA

SPCT2-075/1

167578

EATON - MOELLER

1 Pcs.

Plug-in surge arresters, 1p, 75VAC, 20 kA SPCT2-075/1 For protecting consumer systems against transient overvoltages caused by indirect lightning strikes and switching operations, test class II according to IEC 61643-1+A1, SPD-type T2 according to EN 61643-11, SPC-S-HK auxiliary contact for remote signaling can be added, can be bussed with all Xtra Combinations switchgear

Automation > Surge protection device for power supply systems
Modular Switchgear – Industrial

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Plug-in surge arresters, 1p, 75VAC, 20 kA
For protecting consumer systems against transient overvoltages caused by indirect lightning strikes and switching operations, test class II according to IEC 61643-1+A1, SPD-type T2 according to EN 61643-11, SPC-S-HK auxiliary contact for remote signaling can be added, can be bussed with all Xtra Combinations switchgear

Delivery program

Products
Surge arresters
Application field
Residential buildings
Utility buildings
Open areas

Technical data ETIM 7.0

Earthing, lightning and surge protection (EG000021) / Surge protection device for power supply systems (EC000941)
Electric engineering, automation, process control engineering / Protection installation, device (electric) / Surge protection device (inner lightning protection) / Surge protection device for power supply systems ([email protected] [ACN278011])
System configuration DC
No
System configuration IT
No
System configuration TN
Yes
System configuration TN-C
No
System configuration TN-C-S
No
System configuration TN-S
No
System configuration TT
No
System configuration other
Yes
Number of conductors (without earthing)
1
Nominal discharge surge current (8/20)
20 kA
Nominal voltage AC
75 V
Nominal voltage DC
0 V
Short-circuit breaking capacity (Isccr)
0 kA
Max. continuous voltage AC
75 V
Max. discharge surge current (8/20)
30 kA
Max. continuous voltage DC
0 V
Mounting method
DIN rail (top hat rail) 35 mm
Construction size
1 modular spacing
Max. PV-voltage
0 V
Voltage protection level
0.55 kV
Max. conductor cross section solid (solid, stranded)
25 mm²
Max. conductor cross section flexible (fine-strand)
35 mm²
Voltage protection level L-N
0 kV
Voltage protection level N-PE
0 kV
With remote signalling contact
No
Integrated backup fuse
No
Signalling at the device
Optic
Category type 2
Yes
Degree of protection (IP)
IP20

ETIM for 167578 Earthing, lightning and surge protection (EC000941)
Feature Name Feature Value
System configuration DC (EF009926) No
System configuration IT (EF009927) No
System configuration TN (EF009928) Yes
System configuration TN-C (EF009929) No
System configuration TN-C-S (EF009933) No
System configuration TN-S (EF009930) No
System configuration TT (EF009931) No
System configuration other (EF009932) Yes
Number of conductors (without earthing) (EF001148) 1
Nominal discharge surge current (8/20) (EF004214) 20 kA
Max. discharge surge current (8/20) (EF012274) 30 kA
Nominal voltage AC (EF004220) 75 V
Nominal voltage DC (EF004221) 0 V
Max. continuous voltage AC (EF004198) 75 V
Max. continuous voltage DC (EF004777) 0 V
Max. PV-voltage (EF008795) 0 V
Voltage protection level (EF003525) 0.55 kV
Voltage protection level L-N (EF004236) 0 kV
Voltage protection level N-PE (EF008796) 0 kV
Max. overcurrent protection device, parallel connection (fuse) (EF015962) 0 A
Max. overcurrent protection device, series connection (fuse) (EF015963) 125 A
Short-circuit breaking capacity (Isccr) (EF012627) 0 kA
Integrated short-circuit protection (EF016000) No
Integrated short-circuit protection selective to fuse gG (EF016001) 0 A
Integrated backup fuse (EF008797) No
Leakage-current free (EF016002) No
Mounting method (EF000003) DIN rail (top hat rail) 35 mm
Construction size (EF002566) 1 modular spacing
Max. conductor cross section solid (solid, stranded) (EF008827) 25 mm²
Max. conductor cross section flexible (fine-strand) (EF008828) 35 mm²
With remote signalling contact (EF000422) No
Signalling at the device (EF004241) Optic
Category type 2 (EF004230) Yes
Degree of protection (IP) (EF005474) IP20

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
