EATON - MOELLER EME3PCT EME3PCT 167417 EATON ELECTRIC Power meter, 3 N, 5 A x, ct View larger
Images are for illustrative purposes only. Please refer to data sheet for details

EME3PCT 167417 EATON ELECTRIC Power meter, 3 N, 5 A x, ct

EME3PCT

167417

EATON - MOELLER

1 Pcs.

Power meter, 3 N, 5 A_x, ct 3N 5A,CT Energy Meter Real and reactive power meter for three-phase alternating current with digital counter, displays up to 8 numbers (2 decimals). With 2 S0 interfaces for real/reactive power and 2 tariffs (MID device: real power display only), green, backlit LCD display, for direct connection up to 80 A or for current transformer connection with a current of .../5 A, for primary current transformer current of 5 A to 10,000/5 A . Specified in 5 A increments, display with 8 numbers for showing 8 power registers, wrong connection signal (phase mix-up), accuracy class 1 for real power and power as per EN 50470-3 (B), accuracy class 2 for reactive power and power as per EN 62053-23, perfect operating current range (Ist ... Imax), for direct connection 80 A = 0.015 ... 80 A, for direct connection CT .../5 A = 0.003 ... 5 A, standard version with communications-capable add-on of 1 space units, bus transmission, power register can be set to zero (not on MID type), power register for input and output, displays instantaneous real or reactive power, sealable terminal covers

Automation > Kilowatt-hour meter
Modular Switchgear – Others and Accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Power meters such as the EME3PCT Eaton Moeller device provide accurate tracking of electrical energy distribution and consumption parameters within industrial power systems. These robust measurement components integrate into electrical panels to support comprehensive power management and load evaluation initiatives.

Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Type of meter (EF005441): Electromechanical
  • Nominal current (In) (EF008873): 6 A
  • Max. current (Imax) (EF000877): 6 A
  • Nominal voltage (Un) N-L (EF008871): 184 V
  • Nominal voltage (Un) L-L (EF008872): 319 V
  • Frequency (EF000416): 50 Hz
  • Accuracy class (EF008842): B
  • Pole type (EF008843): Three conductor
  • Model (EF000010): Measurement transformer
  • Energy type (EF007135): Effective power and reactive power
  • Suitable for (EF000073): Purchase/supply
  • Tariff type (EF007550): Two-tariff
  • Tariff control (EF008834): Internal
  • Measurement type load profile (EF008844): No
  • Escapement mechanism (EF008835): No
  • Calibrated (EF008836): No

More info

▲
Power meter, 3N, 5A, ct
Real and reactive power meter for three-phase alternating current with digital counter, displays up to 8 numbers (2 decimals). With 2 S0 interfaces for real/reactive power and 2 tariffs (MID device: real power display only), green, backlit LCD display, for direct connection up to 80 A or for current transformer connection with a current of .../5 A, for primary current transformer current of 5 A to 10,000/5 A. Specified in 5 A increments, display with 8 numbers for showing 8 power registers, wrong connection signal (phase mix-up), accuracy class 1 for real power and power as per EN 50470-3 (B), accuracy class 2 for reactive power and power as per EN 62053-23, perfect operating current range (Ist ... Imax), for direct connection 80 A = 0.015 ... 80 A, for direct connection CT .../5 A = 0.003 ... 5 A, standard version with communications-capable add-on of 1 space units, bus transmission, power register can be set to zero (not on MID type), power register for input and output, displays instantaneous real or reactive power, sealable terminal covers

Technical data ETIM 7.0

Meters (EG000045) / Kilowatt-hour meter (EC001506)
Electric engineering, automation, process control engineering / Electrical installation, device / Modular serial built-in device for electrical circuit distributors / Electronic electricity meter ([email protected] [AFZ828014])
Type of meter
Electromechanical
Nominal current (In)
6 A
Max. current (Imax)
6 A
Nominal voltage (Un) N-L
184 - 276 V
Nominal voltage (Un) L-L
319 - 480 V
Frequency
50 - 50 Hz
Accuracy class
B
Pole type
Three conductor
Model
Measurement transformer
Energy type
Effective power and blind power
Suitable for
Purchase/supply
Tariff type
Two-tariff
Tariff control
Internal
Measuring type load profile
No
Escapement mechanism
No
Calibrated
No
Approval
Measuring Instruments Directive
Pulse output
Electrical
Pulse type
S0
Pulse rate
0 - 0 Imp/kWh (kvarh)
Type of indication
Digital
Mounting method
DRA (DIN-rail adapter)
Width in number of modular spacings
4.1
Type of interface
Other
EEC40 signature
No
With lock code
Yes
Number of positions total (counter)
8
Degree of protection (IP)
IP20
Degree of protection (NEMA)

Product Datasheet
