EATON - MOELLER EME3P125MID EME3P125MID 167416 EATON ELECTRIC Power meter, 3 N, 125 A x, MID View larger
Images are for illustrative purposes only. Please refer to data sheet for details

EME3P125MID 167416 EATON ELECTRIC Power meter, 3 N, 125 A x, MID

EME3P125MID

167416

EATON - MOELLER

1 Pcs.

Power meter, 3 N, 125 A_x, MID 3N 125A MID Energy Meter Digital real/reactive power meter with instantaneous real/reactive power display and IR communication interface on the side - 2 tariffs - 2 S0 (MID device: only shows real power), real and reactive power meter for three-phase alternating current with digital counter, displays up to 8 numbers (2 decimals). With 2 S0 interfaces for real/reactive power and 2 tariffs, green backlit LCD display, for direct connection up to 125 A, display with 8 numbers for showing 8 power registers, wrong connection signal (phase mix-up), accuracy class 1 for real power and power as per EN 50470-3 (B) , accuracy class 2 for reactive power and power as per EN 62053-23, perfect operating current range (Ist ... Imax) for directly connecting 125 A = 0.020 ... 125 A, standard version with communications-capable add-on of 1 space units, bus transmission, power register can be set to zero (not on MID type), power register for input and output, displays instantaneous real or reactive power (MID device: does not display reactive power), sealable terminal covers

Automation > Kilowatt-hour meter
Modular Switchgear – Others and Accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Power meter, 3N, 125A, MID
Digital real/reactive power meter with instantaneous real/reactive power display and IR communication interface on the side - 2 tariffs - 2 S0 (MID device: only shows real power), real and reactive power meter for three-phase alternating current with digital counter, displays up to 8 numbers (2 decimals). With 2 S0 interfaces for real/reactive power and 2 tariffs, green backlit LCD display, for direct connection up to 125 A, display with 8 numbers for showing 8 power registers, wrong connection signal (phase mix-up), accuracy class 1 for real power and power as per EN 50470-3 (B), accuracy class 2 for reactive power and power as per EN 62053-23, perfect operating current range (Ist ... Imax) for directly connecting 125 A = 0.020 ... 125 A, standard version with communications-capable add-on of 1 space units, bus transmission, power register can be set to zero (not on MID type), power register for input and output, displays instantaneous real or reactive power (MID device: does not display reactive power), sealable terminal covers

Technical data ETIM 7.0

Meters (EG000045) / Kilowatt-hour meter (EC001506)
Electric engineering, automation, process control engineering / Electrical installation, device / Modular serial built-in device for electrical circuit distributors / Electronic electricity meter ([email protected] [AFZ828014])
Type of meter
Electromechanical
Nominal current (In)
125 A
Max. current (Imax)
125 A
Nominal voltage (Un) N-L
184 - 276 V
Nominal voltage (Un) L-L
319 - 480 V
Frequency
50 - 50 Hz
Accuracy class
B
Pole type
Three conductor
Model
Direct measurement
Energy type
Effective power and blind power
Suitable for
Purchase/supply
Tariff type
Two-tariff
Tariff control
Internal
Measuring type load profile
No
Escapement mechanism
No
Calibrated
Yes
Approval
Measuring Instruments Directive
Pulse output
Electrical
Pulse type
S0
Pulse rate
0 - 0 Imp/kWh (kvarh)
Type of indication
Digital
Mounting method
DRA (DIN-rail adapter)
Width in number of modular spacings
7.3
Type of interface
Other
EEC40 signature
No
With lock code
Yes
Number of positions total (counter)
8
Degree of protection (IP)
IP20
Degree of protection (NEMA)

ETIM for 167416 Meters (EC001506)
Feature Name Feature Value
Type of meter (EF005441) Electromechanical
Nominal current (In) (EF008873) 125 A
Max. current (Imax) (EF000877) 125 A
Nominal voltage (Un) N-L (EF008871) 184 V
Nominal voltage (Un) L-L (EF008872) 319 V
Frequency (EF000416) 50 Hz
Accuracy class (EF008842) B
Pole type (EF008843) Three conductor
Model (EF000010) Direct measurement
Energy type (EF007135) Effective power and reactive power
Suitable for (EF000073) Purchase/supply
Tariff type (EF007550) Two-tariff
Tariff control (EF008834) Internal
Measurement type load profile (EF008844) No
Escapement mechanism (EF008835) No
Calibrated (EF008836) Yes
Approval (EF008837) Measuring Instruments Directive
Pulse output (EF008838) Electrical
Pulse type (EF008839) S0
Pulse rate (EF008840) 0 Imp/kWh (kvarh)
Type of indication (EF000306) Digital
Mounting method (EF000003) DRA (DIN-rail adapter)
Width in number of modular spacings (EF002950) 7.3
Width (EF000008) 108 mm
Depth (EF000049) 90 mm
Height (EF000040) 70 mm
Type of interface (EF006977) Other
EEC40 signature (EF008845) No
With lock code (EF008846) Yes
Number of positions total (counter) (EF004442) 8
Degree of protection (IP) (EF005474) IP20
