EATON - MOELLER ASOHC230 ASOHC230 167424 EATON ELECTRIC Power Distribution Components IEC Miniature circuit breaker View larger
Images are for illustrative purposes only. Please refer to data sheet for details

ASOHC230 167424 EATON ELECTRIC Power Distribution Components IEC Miniature circuit breaker

ASOHC230

167424

EATON - MOELLER

1 Pcs.

Power Distribution Components IEC Miniature circuit breaker 230V Operating Hour Counter Operating hour meters, 230V 50Hz High-quality residual current circuit-breaker/miniature circuit-breaker with overcurrent protection independent of mains voltage; contact position display red-green; terminal rear plug protection; tri-stable slide catch—enables removal from an existing closure assembly; comprehensive accessory product range can be retrofitted; wide range of rated fault currents; rated operational currents up to 40 A; trip types B,C,D; rated switching capacity 10 kA; suitable for use in the free (on-site power and outdoor distribution board) to -25 °C; suitable for use in the free (on-site power and outdoor distribution board) to -25 °C

Automation > Hour meter
Modular Switchgear – Others and Accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

The ASOHC230 167424 EATON ELECTRIC Power Distribution Components IEC Miniature circuit breaker serves as an analog operating hours counter designed to measure active running times in industrial machinery panels. Facilities personnel rely on such meters to schedule timely part replacements and monitor operational workloads. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Mounting method (EF000003): DIN rail
  • Model (EF000010): Analogue
  • Count area (EF005440): 10000 h
  • Operation indication (EF004881): Yes
  • Number of digits (EF005555): 7
  • Input voltage (EF003840): 230 V
  • Voltage type (EF000187): AC
  • Frequency input voltage (EF006705): 50 Hz
  • Type of drive (EF001422): Mains synchronous
  • Accuracy per day (EF006325): 0.02 s
  • Width (EF000008): 36 mm
  • Height (EF000040): 70 mm
  • Width in number of modular spacings (EF002950): 2.1
  • Built-in depth (EF000218): 70 mm
  • Front plate width (EF004689): 36 mm
  • Front plate height (EF004690): 45 mm

More info

▲
EL-Nummer (Norway)
0004133961
Operating hour meters, 230V 50Hz
High-quality residual current circuit-breaker/miniature circuit-breaker with overcurrent protection independent of mains voltage; contact position display red-green; terminal rear plug protection; tri-stable slide catch—enables removal from an existing closure assembly; comprehensive accessory product range can be retrofitted; wide range of rated fault currents; rated operational currents up to 40 A; trip types B,C,D; rated switching capacity 10 kA; suitable for use in the free (on-site power and outdoor distribution board) to -25 °C; suitable for use in the free (on-site power and outdoor distribution board) to -25 °C

Technical data ETIM 7.0

Meters (EG000045) / Hour meter (EC001641)
Electric engineering, automation, process control engineering / Electrical installation, device / Modular serial built-in device for electrical circuit distributors / Elapsed time meter ([email protected] [AFZ825013])
Mounting method
DIN rail
Model
Analogue
Count area
10000 h
Reset function
None
Operation indication
Yes
Number of digits
7
Input voltage
230 - 230 V
Voltage type
AC
Frequency input voltage
50 - 60 Hz
Type of drive
Mains synchronous
Accuracy per day
0.02 s
Width
36 mm
Height
70 mm
Width in number of modular spacings
2.1
Built-in depth
70 mm
Front plate width
36 mm
Front plate height
45 mm
Diameter panel opening
0 mm
Mounting to max. wall thickness
0 mm
Degree of protection (IP)
IP20
Degree of protection (NEMA)
