View larger
Images are for illustrative purposes only. Please refer to data sheet for details
E55CBL18T110E 135842 Y7-135842 EATON ELECTRIC Proximity switch, inductive, 1 N/C, Sn 8mm, 3L, 10-30VDC, NPN,..
E55CBL18T110E
135842
Y7-135842
EATON - MOELLER
1 Pcs.
Proximity switch, inductive, 1 N/C, Sn=8mm, 3L, 10-30VDC, NPN, M12, insulated material, line 2m
E55CBL18T110E
Automation > Inductive proximity switch
Sensors
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Proximity switch, inductive, 1 N/C, Sn=8mm, 3L, 10-30VDC, NPN, M12, insulated material, line 2m
Proximity switch, Inductive Sensors, Product range: E55 Limit Switch Style Series, Connection: 3-wire, Design (outer dimensions): M18 x 1 mm, Rated operational voltage: Ue= 10 - 30 V DC, Rated switching distance: Sn= 8 mm, Type of mounting: Non-flush, Switching type: NPN, 2 m connection cable, Contacts N/C = Normally closed: 1 NC, Material: Insulated material, Degree of Protection: IP66, Standards: IEC/EN 60947-5-2
Delivery program
Basic function
Inductive Sensors
Product range
E55 Limit Switch Style Series
Connection
3-wire
Design (outer dimensions)
M18 x 1 mm
Rated operational voltage [Ue]
10 - 30 V DC
Rated switching distance [Sn]
8 mm
Type of mounting
Non-flush
Switching type
NPN
For connection of:
2 m connection cable
Contacts
N/C = Normally closed
1 NC
Material
Insulated material
Degree of Protection
IP66
Technical data
General
Standards
IEC/EN 60947-5-2
Ambient temperature
-25 - +70
Mechanical shock resistance
30
Shock duration 11 ms g
Shock duration 11 ms g
Degree of Protection
IP66
Characteristics
Rated switching distanceRated switching distance [Sn]
8 mm
Repetition accuracy of Sn
10 %
Temperature drift of Sn
10 %
Switching hysteresis of Sn
20 %
Rated operational voltage [Ue]
10 - 30 V DC
Supply frequency
50 - 60
Residual ripple of Ue
10 %
Maximum load current [Ie]
< 200 mA
Voltage drop at Ie[Ud]
8 V
Switching Frequency
500 Hz
Switching state display
Red LED
Protective functions
Short-circuit protective device
Protection against polarity reversal
Protection against polarity reversal
Connection
3-wire
ContactsN/C = Normally closed
1 NC
StyleDesign (outer dimensions)
M18 x 1 mm
For connection of:
2 m connection cable
Material
Insulated material
Design verification as per IEC/EN 61439
Operating ambient temperature min.
-25 °C
Operating ambient temperature max.
+70 °C
Technical data ETIM 7.0
Sensors (EG000026) / Inductive proximity switch (EC002714)
Electric engineering, automation, process control engineering / Binary sensor technology, safety-related sensor technology / Proximity switch / Inductive proximity switch ([email protected] [AGZ376015])
Width sensor
0 mm
Height of sensor
0 mm
Length of sensor
55 mm
Diameter sensor
18 mm
Mechanical mounting condition for sensor
Not flat
Switching distance
8 mm
Suitable for safety functions
No
Type of switch function
Breaker contact
Type of switching output
NPN
Type of electric connection
Cable
Number of semiconductor outputs with signalling function
1
Number of contact energized outputs with signalling function
0
Number of protected semiconductor outputs
0
Number of protected contact energized outputs
0
Type of actuation
Metallic Target
Type of interface
None
Type of interface for safety communication
None
Construction type housing
Cylinder, screw-thread
Coating housing
Other
Cascadable
No
Category according to EN 954-1
B
SIL according to IEC 61508
None
Performance level acc. EN ISO 13849-1
None
Max. output current at protected output
0 mA
Supply voltage
10 - 30 V
Rated control supply voltage Us at AC 50HZ
0 - 0 V
Rated control supply voltage Us at AC 60HZ
0 - 0 V
Rated control supply voltage Us at DC
10 - 30 V
Voltage type
DC
Switching frequency
500 Hz
With monitoring function downstream switching devices
No
Material housing
Plastic
Compression-resistant
No
Explosion safety category for gas
None
Explosion safety category for dust
None
Interference resistance to magnetic fields
Approvals
Product Standards
CE marking
Max. Voltage Rating
30 V DC
Degree of Protection
IEC: IP66; UL/CSA: NEMA 4, 4X, 13
Dimensions
