E55BLT1D 135813 Y7-135813 EATON ELECTRIC Proximity switch, inductive, 1N/O/1N/C, Sn 20mm, 2L, 35-250VAC, qua..
E55BLT1D
135813
Y7-135813
EATON - MOELLER
1 Pcs.
Automation > Inductive proximity switch
Sensors
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The Eaton Moeller E55BLT1D cuboid inductive proximity switch provides dependable position sensing for industrial machinery and material handling systems. Engineers frequently use rectangular block-style proximity sensors in applications requiring flexible mounting geometries and extended sensing ranges. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Width sensor (EF007094): 40 mm
- Height of sensor (EF007283): 40 mm
- Length of sensor (EF007334): 118 mm
- Diameter sensor (EF007111): 0 mm
- Mechanical mounting condition for sensor (EF004041): Not flat
- Switching distance (EF003647): 20 mm
- Suitable for safety functions (EF001597): No
- Type of switch function (EF003963): Programmable/configurable
- Type of switching output (EF003962): 2-wire
- Type of electric connection (EF003961): Clamp
- Number of protected semiconductor outputs (EF003951): 0
- Number of protected contact energized outputs (EF003952): 0
- Type of actuation (EF006949): Metallic Target
- Construction type housing (EF004008): Cuboid
- Cascadable (EF000507): No
- Max. output current at protected output (EF004035): 0 mA
More info
▲General specifications
CE
Product specifications
Short-circuit protection
Protection against wire breakage
Screw terminal
NEMA 4X, 6, 13
Status indication of Switching state: Red LED
60 Hz, Input, max. Range
