> EATON - MOELLER > Bussmann Series High speed fuses > 170M5667
EATON - MOELLER FUSE 1100A 600V 2FKE/90 AR UC FUSE 1100A 600V 2FKE/90 AR UC 170M5667 EATON ELECTRIC Fuse-link, high speed, 1100 A, AC 600 V, size 2, 61 x .. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

FUSE 1100A 600V 2FKE/90 AR UC 170M5667 EATON ELECTRIC Fuse-link, high speed, 1100 A, AC 600 V, size 2, 61 x ..

FUSE 1100A 600V 2FKE/90 AR UC

170M5667

170M5667

EATON - MOELLER

3 Pcs.

Fuse-link, high speed, 1100 A, AC 600 V, size 2, 61 x 77 x 135 mm, aR, IEC, UL, type K indicator, 90 mm centres FUSE 1100A 600V 2FKE/90 AR UC Fuse-link, high speed, 1100A, AC 600 V, 200 kAIC, Other, Fuse, Blade end X blade end, Class aR

Automation > Low Voltage HRC fuse
Bussmann Series High speed fuses

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

General specifications

Product Name
Eaton Bussmann series high speed square body fuse
Catalog Number
170M5667
EAN
5027590458177
UPC
051712262064
Product Length/Depth
286 mm
Product Height
66 mm
Product Width
165 mm
Product Weight
318 g
Compliances
CE Marked
RoHS Compliant
Certifications
IEC Rated
UL Recognized

Electrical data

Amperage Rating
1100 A
Voltage rating
600 V
Voltage type
AC
Clearing (I2T)
1600000 at 660 V
Pre arc (I2T)
245000
Watt losses
120 W
Breaking capacity
200 kA
Class
Class aR

Product specification

Fuse size
2
Fitted with:
Type K Indicator for micro

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
