EATON - MOELLER High Speed - Square Body High Speed Square Body 170M3158 EATON ELECTRIC Fuse-link, high speed, 40 A, AC 690 V, compact size 1, 45 x 4.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

High Speed Square Body 170M3158 EATON ELECTRIC Fuse-link, high speed, 40 A, AC 690 V, compact size 1, 45 x 4..

High Speed - Square Body

170M3158

EATON - MOELLER

6 Pcs.

Fuse-link, high speed, 40 A, AC 690 V, compact size 1, 45 x 45 x 134 mm, aR, DIN, IEC, single indicator FUSE 40A 690V 1*/110 AR UC FUSE 40A 690V 1*/110 AR UC - Fuse-link, high speed, 40 A, AC 690 V, 200 kA, compact size 1, 45 x 45 x 134 mm, aR, DIN, IEC, single indicator

Automation > Low Voltage HRC fuse
Bussmann Series High speed fuses

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Fuse-link, high speed, 40 A, AC 690 V, 200 kA, compact size 1, 45 x 45 x 134 mm, aR, DIN, IEC, single indicator
Fuse, Fuse-link, high speed, 40 A, AC 690 V, compact size 1, 45 x 45 x 134 mm, aR, DIN, IEC, single indicator, square body with centre-bolted tags (slotted), semiconductor protection, DIN 43653, IEC 60269-4, Breaking Capacity 200 kA

Delivery program

Product range
Fuse
Basic function
Fuse-link
Field of application
high speed
Rated current [I]
40 A
Rated voltage
AC 690 V
Construction size
compact size 1
Size
45 x 45 x 134 mm
Utilization category
aR
Status indicator
single indicator
Breaking Capacity
200 kA
usable for size/applications
semiconductor protection
Standard/Approval
DIN
IEC
Shape
square body with centre-bolted tags (slotted)
Standards/Regulations
DIN 43653
IEC 60269-4

Technical data ETIM 7.0

Circuit breakers and fuses (EG000020) / Low Voltage HRC fuse (EC000055)
Electric engineering, automation, process control engineering / Electrical installation, device / Safety fuse inserts / Low-Voltage HRC fuse ([email protected] [AFZ800015])
Construction size
Other
Rated current
40 A
Rated voltage
690 V
Voltage type
AC
Rated switching capacity
200 kA
Utilization category
aR (accompanied semiconductor protection)
Type of fuse status indicator
Top fuse status indicator
Insulated metal gripping lugs (IMGL)
No
