EATON - MOELLER FUSE 700A 1000V 3TN/110 AR UR FUSE 700A 1000V 3TN/110 AR UR 170M8636 EATON ELECTRIC Fuse-link, high speed, 700 A, AC 1000 V, DIN 3, 74 x 9.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

FUSE 700A 1000V 3TN/110 AR UR 170M8636 EATON ELECTRIC Fuse-link, high speed, 700 A, AC 1000 V, DIN 3, 74 x 9..

FUSE 700A 1000V 3TN/110 AR UR

170M8636

170M8636

EATON - MOELLER

1 Pcs.

Fuse-link, high speed, 700 A, AC 1000 V, DIN 3, 74 x 90 x 139 mm, aR, DIN, IEC, single indicator FUSE 700A 1000V 3TN/110 AR UR

Automation > Low Voltage HRC fuse
Bussmann Series High speed fuses

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

The Eaton Moeller FUSE 700A 1000V 3TN/110 AR UR 170M8636 is a high-speed square body fuse built for demanding power distribution and conversion applications. In industrial automation environments, such high-capacity fuses protect critical semiconductor devices from destructive overcurrents during faults. Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Manufacturer: Eaton Moeller
  • Manufacturer part number: FUSE 700A 1000V 3TN/110 AR UR
  • Catalogue code: 170M8636
  • Catalogue title: FUSE 700A 1000V 3TN/110 AR UR 170M8636 EATON ELECTRIC Fuse-link, high speed, 700 A, AC 1000 V, DIN 3, 74 x 9..
  • Product description: General specifications Product Name Eaton Bussmann series high speed square body fuse Catalog Number 170M8636 EAN 5996516022610 UPC 051712604383 Product Length/Depth 141 mm Product Height 76 mm Product Width 82.5 mm Prod
  • Manufacturer summary: Fuse-link, high speed, 700 A, AC 1000 V, DIN 3, 74 x 90 x 139 mm, aR, DIN, IEC, single indicator FUSE 700A 1000V 3TN/110 AR UR

More info

▲

General specifications

Product Name
Eaton Bussmann series high speed square body fuse
Catalog Number
170M8636
EAN
5996516022610
UPC
051712604383
Product Length/Depth
141 mm
Product Height
76 mm
Product Width
82.5 mm
Product Weight
1275 g
Compliances
CE Marked
RoHS Compliant
Certifications
IEC Rated
UL Recognized

Electrical data

Amperage Rating
700 A
Voltage rating
1000 V (IEC)
Voltage type
AC/DC
Clearing (I2T)
700000 at 1000 V
Pre arc (I2T)
115000
Watt losses
122 W
Breaking capacity
125 kA
Class
Class aR

Product specification

Fuse size
3
