FRCMM-80/4/01-B 187807 Y7-187807 EATON ELECTRIC AC/DC sensitive residual current circuit-breakers, 80A, 4p, ..
FRCMM-80/4/01-B
187807
Y7-187807
EATON - MOELLER
1 Pcs.
Automation > Residual current circuit breaker (RCCB)
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Eaton Moeller FRCMM-80/4/01-B AC/DC sensitive residual current circuit-breakers provide high-amperage leakage protection for industrial installations operating with complex electronic loads and power converters. These four-pole devices detect both alternating and direct fault currents to maintain rigorous electrical safety compliance.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Number of poles (EF001391): 4
- Rated voltage (EF000228): 240 V
- Rated current (EF000227): 80 A
- Rated fault current (EF002358): 0.1 A
- Rated insulation voltage Ui (EF001366): 440 V
- Rated impulse withstand voltage Uimp (EF011980): 4 kV
- Mounting method (EF000003): DIN rail
- Leakage current type (EF002560): B
- Selective protection (EF002561): No
- Short-time delayed tripping (EF003604): No
- Short-circuit breaking capacity (Icw) (EF002562): 10 kA
- Surge current capacity (EF002564): 3 kA
- Voltage type (EF000187): AC
- With interlocking device (EF007385): Yes
- Frequency (EF005455): 50 Hz
- Additional equipment possible (EF008148): Yes
More info
▲General specifications
IEC/EN 62423
Delivery program
- FRCmM
- Residual current circuit breakers
- Type B
Technical data - electrical
Technical data - mechanical
DIN rail
IP20
1.5 mm² - 50 mm²
1.5 mm² - 5 mm²
Design verification as per IEC/EN 61439 - technical data
Design verification as per IEC/EN 61439
Additional information
Residual current circuit breaker
- Current test marks as per inscription
- Maximum operating temperature is 75 °C: Starting at 40 °C, the max. permissible continuous current decreases by 1.2% for every 1 °C
Residual current circuit breakers
Type B
