FRBDM-D6/2/003-G/A 168207 Y7-168207 EATON ELECTRIC RCD/MCB comb. switch, 6A, 30mA, miniature circuit-breaker..
FRBDM-D6/2/003-G/A
168207
Y7-168207
EATON - MOELLER
1 Pcs.
Automation > Earth leakage circuit breaker
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Designed for advanced circuit protection, this Eaton Moeller RCD/MCB combination switch integrates residual current sensing with overcurrent breaking capabilities to secure electrical installations. Devices of this category are standard in modern electrical enclosures, offering defense against thermal overloads, short circuits, and leakage currents in a space-saving footprint.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Number of poles (total) (EF008618): 2
- Number of protected poles (EF005548): 2
- Rated voltage (EF000228): 240 V
- Rated insulation voltage Ui (EF001366): 250 V
- Rated impulse withstand voltage Uimp (EF011980): 4 kV
- Rated current (EF000227): 6 A
- Rated fault current (EF002358): 0.03 A
- Leakage current type (EF002560): A
- Current limiting class (EF002568): 3
- Power loss (EF005387): 2.5 W
- Disconnection characteristic (EF012587): Short-time delayed
- Surge current capacity (EF002564): 3 kA
- Voltage type (EF000187): AC
- Frequency (EF005455): 50 Hz
- Release characteristic (EF000889): D
- Concurrently switching neutral conductor (EF005997): No
More info
▲General specifications
RoHS conform
