FRBDM-D16/2/003-G/A 168210 Y7-168210 EATON ELECTRIC RCD/MCB comb. switch, 16A, 30mA, miniature circuit-break..
FRBDM-D16/2/003-G/A
168210
Y7-168210
EATON - MOELLER
1 Pcs.
Automation > Earth leakage circuit breaker
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An Eaton Moeller FRBDM-D16/2/003-G/A RCD/MCB combination switch integrates residual current protection with overcurrent interruption in electrical distribution circuits. Devices of this type safeguard personnel from electric shock while protecting wiring against overloads and short circuits.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Number of poles (total) (EF008618): 2
- Number of protected poles (EF005548): 2
- Rated voltage (EF000228): 240 V
- Rated insulation voltage Ui (EF001366): 250 V
- Rated impulse withstand voltage Uimp (EF011980): 4 kV
- Rated current (EF000227): 16 A
- Rated fault current (EF002358): 0.03 A
- Leakage current type (EF002560): A
- Current limiting class (EF002568): 3
- Power loss (EF005387): 4.3 W
- Disconnection characteristic (EF012587): Short-time delayed
- Surge current capacity (EF002564): 3 kA
- Voltage type (EF000187): AC
- Frequency (EF005455): 50 Hz
- Release characteristic (EF000889): D
- Concurrently switching neutral conductor (EF005997): No
More info
▲General specifications
RoHS conform
