EATON - MOELLER FRBDM-C20/2/003-G/A FRBDM-C20/2/003-G/A 168205 Y7-168205 EATON ELECTRIC RCD/MCB comb. switch, 20A, 30mA, miniature circuit-break.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

FRBDM-C20/2/003-G/A 168205 Y7-168205 EATON ELECTRIC RCD/MCB comb. switch, 20A, 30mA, miniature circuit-break..

FRBDM-C20/2/003-G/A

168205

Y7-168205

EATON - MOELLER

1 Pcs.

RCD/MCB comb. switch, 20A, 30mA, miniature circuit-breaker type C trip characteristic, 2p, residual current circuit-breaker trip characteristic: A FRBDM-C20/2/003-G/A Eaton Moeller series xEffect - FRBdM RCBO - residual-current circuit breaker with overcurrent protection. RCD/MCB, 20A, 30mA, MCB trip type C, 2p, RCCB trip type: A

Automation > Earth leakage circuit breaker
Modular Switchgear – Industrial

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Part number FRBDM-C20/2/003-G/A by Eaton Moeller serves as an RCD/MCB comb. switch designed to detect earth leakage while providing reliable overcurrent protection. These devices are standard in electrical installations requiring high levels of circuit safety and fault isolation. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Manufacturer: Eaton Moeller
  • Manufacturer part number: FRBDM-C20/2/003-G/A
  • Catalogue code: 168205
  • Catalogue title: FRBDM-C20/2/003-G/A 168205 Y7-168205 EATON ELECTRIC RCD/MCB comb. switch, 20A, 30mA, miniature circuit-break..
  • Product description: General specifications Product Name Eaton Moeller series xEffect - FRBdM RCBO - residual-current circuit breaker with overcurrent protection Catalog Number 168205 Model Code FRBDM-C20/2/003-G/A EAN 4015081647750 Product
  • Manufacturer summary: RCD/MCB comb. switch, 20A, 30mA, miniature circuit-breaker type C trip characteristic, 2p, residual current circuit-breaker trip characteristic: A FRBDM-C20/2/003-G/A Eaton Moeller series xEffect - FRBdM RCBO - residual-

More info

▲

General specifications

Product Name
Eaton Moeller series xEffect - FRBdM RCBO - residual-current circuit breaker with overcurrent protection
Catalog Number
168205
Model Code
FRBDM-C20/2/003-G/A
EAN
4015081647750
Product Length/Depth
86 mm
Product Height
75 mm
Product Width
37 mm
Product Weight
0.25 kg
Compliances
CE Marked
RoHS conform
Certifications
CE

Delivery Program

Basic function
Combined RCD/MCB devices
Number of poles
Two-pole
Tripping
Short time-delayed
Tripping characteristic
C
Application
Switchgear for industrial and advanced commercial applications
Rated switching capacity (IEC/EN 61009)
10000 kA
Type
RCBO
Product range
FRBdM
Impulse withstand current
Surge-proof, 3 kA

Technical Data - Electrical

Rated operational voltage (Ue) - max
240 V
Sensitivity type
Pulse-current sensitive
Rated current
20 A

Technical Data

Number of poles (total)
2
Number of poles (protected)
2
Rated impulse withstand voltage (Uimp)
4 kV
Leakage current type
A
Current limiting class
3
Rated short-circuit breaking capacity (EN 61009)
10 kA
Rated short-circuit breaking capacity (EN 61009-1)
10 kA
Rated short-circuit breaking capacity (EN 60947-2)
0 kA
Disconnection characteristic
Short-time delayed
Surge current capacity
3 kA
Voltage type
AC
Release characteristic
C
Overvoltage category
III
Pollution degree
2
