FRBDM-C10/2/001-G/A 168298 Y7-168298 EATON ELECTRIC RCD/MCB comb. switch, 10A, 10mA, miniature circuit-break..
FRBDM-C10/2/001-G/A
168298
Y7-168298
EATON - MOELLER
1 Pcs.
Automation > Earth leakage circuit breaker
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The Eaton Moeller FRBDM-C10/2/001-G/A is an RCD/MCB combination switch designed to protect electrical circuits against both overcurrents and earth leakage faults. Devices of this type are widely deployed in commercial and residential distribution boards to ensure personal safety and prevent equipment damage by interrupting faulty circuits. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Number of poles (total) (EF008618): 2
- Number of protected poles (EF005548): 2
- Rated voltage (EF000228): 240 V
- Rated insulation voltage Ui (EF001366): 250 V
- Rated impulse withstand voltage Uimp (EF011980): 4 kV
- Rated current (EF000227): 10 A
- Rated fault current (EF002358): 0.01 A
- Leakage current type (EF002560): A
- Current limiting class (EF002568): 3
- Power loss (EF005387): 4.4 W
- Disconnection characteristic (EF012587): Short-time delayed
- Surge current capacity (EF002564): 3 kA
- Voltage type (EF000187): AC
- Frequency (EF005455): 50 Hz
- Release characteristic (EF000889): C
- Concurrently switching neutral conductor (EF005997): No
More info
▲General specifications
RoHS conform
