FRBDM-B16/2/003-G/A 168200 Y7-168200 EATON ELECTRIC RCD/MCB comb. switch, 16A, 30mA, miniature circuit-break..
FRBDM-B16/2/003-G/A
168200
Y7-168200
EATON - MOELLER
1 Pcs.
Automation > Earth leakage circuit breaker
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Designed for multi-pole fault protection, the Eaton Moeller FRBDM-B16/2/003-G/A RCD/MCB combination switch monitors circuits for both thermal-magnetic overloads and ground fault currents. Electrical contractors integrate these units into automation systems to ensure compliance with safety standards. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Number of poles (total) (EF008618): 2
- Number of protected poles (EF005548): 2
- Rated voltage (EF000228): 240 V
- Rated insulation voltage Ui (EF001366): 250 V
- Rated impulse withstand voltage Uimp (EF011980): 4 kV
- Rated current (EF000227): 16 A
- Rated fault current (EF002358): 0.03 A
- Leakage current type (EF002560): A
- Current limiting class (EF002568): 3
- Power loss (EF005387): 4.9 W
- Disconnection characteristic (EF012587): Short-time delayed
- Surge current capacity (EF002564): 3 kA
- Voltage type (EF000187): AC
- Frequency (EF005455): 50 Hz
- Release characteristic (EF000889): B
- Concurrently switching neutral conductor (EF005997): false
More info
▲General specifications
RoHS conform
