FRBDM-B13/2/001-G/A 168295 Y7-168295 EATON ELECTRIC RCD/MCB comb. switch, 13A, 10mA, miniature circuit-break..
FRBDM-B13/2/001-G/A
168295
Y7-168295
EATON - MOELLER
1 Pcs.
Automation > Earth leakage circuit breaker
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Eaton Moeller part number FRBDM-B13/2/001-G/A is a specialized combination switch that integrates miniature circuit breaker mechanisms with high-sensitivity residual current detection. It is typically utilized in sensitive electrical installations where precise fault protection and overload prevention are critical. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Number of poles (total) (EF008618): 2
- Number of protected poles (EF005548): 2
- Rated voltage (EF000228): 240 V
- Rated insulation voltage Ui (EF001366): 250 V
- Rated impulse withstand voltage Uimp (EF011980): 4 kV
- Rated current (EF000227): 13 A
- Rated fault current (EF002358): 0.01 A
- Leakage current type (EF002560): A
- Current limiting class (EF002568): 3
- Power loss (EF005387): 5.3 W
- Disconnection characteristic (EF012587): Short-time delayed
- Surge current capacity (EF002564): 3 kA
- Voltage type (EF000187): AC
- Frequency (EF005455): 50 Hz
- Release characteristic (EF000889): B
- Concurrently switching neutral conductor (EF005997): No
