FRBDM-B10/2/003-G/A 168198 Y7-168198 EATON ELECTRIC RCD/MCB comb. switch, 10A, 30mA, miniature circuit-break..
FRBDM-B10/2/003-G/A
168198
Y7-168198
EATON - MOELLER
1 Pcs.
Automation > Earth leakage circuit breaker
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The Eaton Moeller FRBDM-B10/2/003-G/A 168198 Y7-168198 EATON ELECTRIC RCD/MCB comb. switch, 10A, 30mA, miniature circuit-break.. is designed to protect electrical installations against overloads, short circuits, and residual current hazards. These units serve as critical safety components within commercial and industrial power distribution panels.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Number of poles (total) (EF008618): 2
- Number of protected poles (EF005548): 2
- Rated voltage (EF000228): 240 V
- Rated insulation voltage Ui (EF001366): 250 V
- Rated impulse withstand voltage Uimp (EF011980): 4 kV
- Rated current (EF000227): 10 A
- Rated fault current (EF002358): 0.03 A
- Leakage current type (EF002560): A
- Current limiting class (EF002568): 3
- Power loss (EF005387): 4.4 W
- Disconnection characteristic (EF012587): Short-time delayed
- Surge current capacity (EF002564): 3 kA
- Voltage type (EF000187): AC
- Frequency (EF005455): 50 Hz
- Release characteristic (EF000889): B
- Concurrently switching neutral conductor (EF005997): No
More info
▲General specifications
RoHS conform
