FAZ-C32/3-RT 102294 Y7-102294 EATON ELECTRIC Miniature circuit breaker (MCB), 32A, 3p, C-Char, AC
FAZ-C32/3-RT
102294
Y7-102294
EATON - MOELLER
1 Pcs.
Automation > Miniature circuit breaker (MCB)
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An FAZ-C32/3-RT 102294 Y7-102294 EATON ELECTRIC Miniature circuit breaker (MCB), 32A, 3p, C-Char, AC is a multi-pole switching unit engineered to automatically break electrical circuits during overcurrent events. These protective components are widely used in industrial power distribution panels to safeguard three-phase machinery and distribution branches.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Built-in depth (EF000218): 70.5 mm
- Release characteristic (EF000889): C
- Number of poles (total) (EF008618): 3
- Number of protected poles (EF005548): 3
- Rated current (EF000227): 32 A
- Rated voltage (EF000228): 415 V
- Rated insulation voltage Ui (EF001366): 440 V
- Rated impulse withstand voltage Uimp (EF011980): 4 kV
- Voltage type (EF000187): AC
- Frequency (EF000416): 50 Hz
- Power loss (EF005387): 10.5 W
- Current limiting class (EF002568): 3
- Flush-mounted installation (EF007517): No
- Concurrently switching neutral conductor (EF005997): No
- Over voltage category (EF002569): 3
- Pollution degree (EF002570): 2
More info
▲General specifications
CE marking
CSA (Class No. 1432-01)
UL 489, CSA C22.2 No. 5
Specially designed for North America, suitable as BCPD
IEC 60947-2
IEC/EN 60947-2
UL (File No. E235139)
UL 489
North America (UL listed, CSA certified)
CSA-C22.2 No. 5-09
UL (Category Control Number DIVQ)
EN45545-2
IEC 61373
Programa de entrega
- Feeder circuits, branch circuits
- Switchgear for industrial and advanced commercial applications
- xEffect - Switchgear for industrial and advanced commercial applications
- FAZ-RT
- Miniature circuit breaker
Datos técnicos - eléctricos
Datos técnicos - mecánicos
UL/CSA Type: -
IP20 (IEC)
IP20
UL: 4 Nm (36 lb-in) for AWG 6
Max. 2.4 Nm
UL: 2.4 Nm (21 lb-in) for AWG 18 - AWG 12
Verificación del diseño según IEC/EN - datos técnicos
Verificación del diseño según la norma IEC/EN 61439
Información adicional
FAZ-RT
