FAZ-B3/3-RT 132772 Y7-132772 EATON ELECTRIC Miniature circuit breaker (MCB), 3A, 3p, B-Char, AC
FAZ-B3/3-RT
132772
Y7-132772
EATON - MOELLER
1 Pcs.
Automation > Miniature circuit breaker (MCB)
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Eaton Moeller part number FAZ-B3/3-RT (132772) is a miniature circuit breaker (MCB) engineered for reliable electrical circuit protection against overloads and short circuits. These protective components are widely utilized in commercial power distribution to safeguard connected equipment and wiring.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Built-in depth (EF000218): 70.5 mm
- Release characteristic (EF000889): B
- Number of poles (total) (EF008618): 3
- Number of protected poles (EF005548): 3
- Rated current (EF000227): 3 A
- Rated voltage (EF000228): 415 V
- Rated insulation voltage Ui (EF001366): 440 V
- Rated impulse withstand voltage Uimp (EF011980): 4 kV
- Voltage type (EF000187): AC
- Frequency (EF000416): 50 Hz
- Power loss (EF005387): 6.6 W
- Current limiting class (EF002568): 3
- Flush-mounted installation (EF007517): No
- Concurrently switching neutral conductor (EF005997): No
- Over voltage category (EF002569): 3
- Pollution degree (EF002570): 2
More info
▲IEC/EN 60947-2
UL (Category Control Number DIVQ)
CSA-C22.2 No. 5-09
CSA (Class No. 1432-01)
North America (UL listed, CSA certified)
Specially designed for North America, suitable as BCPD
UL (File No. E235139)
CSA (File No. 204453)
UL 489, CSA C22.2 No. 5
UL 489
CE marking
IEC 61373
EN45545-2
Switchgear for industrial and advanced commercial applications
xEffect - Switchgear for industrial and advanced commercial applications
Miniature circuit breaker
IP20 (IEC)
IP20
IP40 (when fitted)
UL: 2.8 Nm (25 lb-in) for AWG 10 - AWG 8
UL: 4 Nm (36 lb-in) for AWG 6
UL: 2.4 Nm (21 lb-in) for AWG 18 - AWG 12
Miniature circuit breaker
