FAZ-B3/2-RT 132753 Y7-132753 EATON ELECTRIC Miniature circuit breaker (MCB), 3A, 2p, B-Char, AC
FAZ-B3/2-RT
132753
Y7-132753
EATON - MOELLER
1 Pcs.
Automation > Miniature circuit breaker (MCB)
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Operating as a dual-pole protective device, the Eaton Moeller FAZ-B3/2-RT 132753 Y7-132753 EATON ELECTRIC Miniature circuit breaker (MCB) prevents electrical damage by interrupting overcurrent conditions across dual lines. Two-pole distribution setups routinely rely on these breakers to isolate faults safely in commercial installations. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Built-in depth (EF000218): 70.5 mm
- Release characteristic (EF000889): B
- Number of poles (total) (EF008618): 2
- Number of protected poles (EF005548): 2
- Rated current (EF000227): 3 A
- Rated voltage (EF000228): 415 V
- Rated insulation voltage Ui (EF001366): 440 V
- Rated impulse withstand voltage Uimp (EF011980): 4 kV
- Voltage type (EF000187): AC
- Frequency (EF000416): 50 Hz
- Power loss (EF005387): 4.4 W
- Current limiting class (EF002568): 3
- Flush-mounted installation (EF007517): No
- Concurrently switching neutral conductor (EF005997): No
- Over voltage category (EF002569): 3
- Pollution degree (EF002570): 2
More info
▲UL (Category Control Number DIVQ)
CSA-C22.2 No. 5-09
IEC/EN 60947-2
CE marking
UL 489, CSA C22.2 No. 5
UL (File No. E235139)
CSA (Class No. 1432-01)
CSA (File No. 204453)
Specially designed for North America, suitable as BCPD
UL 489
IEC 60947-2
EN45545-2
IEC 61373
Switchgear for industrial and advanced commercial applications
xEffect - Switchgear for industrial and advanced commercial applications
Miniature circuit breaker
IP40 (when fitted)
IP20
IP20 (IEC)
Max. 2.4 Nm
UL: 2.4 Nm (21 lb-in) for AWG 18 - AWG 12
UL: 4 Nm (36 lb-in) for AWG 6
Miniature circuit breaker
