EBH4O3TM2-16 EATON ELECTRIC disconnector, BT, 1600 A, 400 V AC, NH4a, AC22B, 3P, IEC
EBH4O3TM2-16
EBH4O3TM216
EATON - MOELLER
1 Pcs.
Connectors > Fuse switch disconnector
Bussmann Series Low Voltage fuses and accessories
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
EBH4O3TM2-16 EATON ELECTRIC disconnector, BT, 1600 A, 400 V AC, NH4a, AC22B, 3P, IEC acts as a high-capacity switching device configured to isolate heavy industrial electrical supplies and protect downstream equipment. Large-scale power distribution systems utilize such robust disconnectors to safely interrupt substantial electrical currents during servicing and emergency shutdowns. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Version as main switch (EF006981): No
- Version as safety switch (EF006985): No
- Max. rated operation voltage Ue AC (EF007355): 690 V
- Rated permanent current Iu (EF001389): 1600 A
- Rated operation power at AC-23, 400 V (EF007027): 0.64 kW
- Conditioned rated short-circuit current Iq (EF001444): 0.05 kA
- Rated short-time withstand current lcw (EF007050): 50 kA
- Suitable for fuses (EF006692): NH4a
- Number of poles (EF001391): 3
- With error protection (EF007384): No
- Type of electrical connection of main circuit (EF006819): Screw connection
- Equipped with connectors (EF011696): No
- Suitable for floor mounting (EF007243): No
- Suitable for front mounting (EF007246): Yes
- Suitable for busbar mounting (EF007259): No
- Type of control element (EF006976): Cover grip
More info
▲General specifications
IEC 60947-3
