EBH4O3SM2-16 EATON ELECTRIC disconnector, BT, 1600 A, 400 V AC, NH4a, AC22B, 3P, IEC
EBH4O3SM2-16
EBH4O3SM216
EATON - MOELLER
1 Pcs.
Connectors > Fuse switch disconnector
Bussmann Series Low Voltage fuses and accessories
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The EBH4O3SM2-16 EATON ELECTRIC disconnector, BT, 1600 A, 400 V AC, NH4a, AC22B, 3P, IEC from Eaton Moeller is built for high-amperage industrial power switching, providing secure load disconnection and fuse protection for heavy-duty electrical systems. Such high-capacity disconnectors are essential in large sub-distribution panels. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Version as main switch (EF006981): No
- Version as safety switch (EF006985): No
- Max. rated operation voltage Ue AC (EF007355): 690 V
- Rated permanent current Iu (EF001389): 1600 A
- Rated operation power at AC-23, 400 V (EF007027): 0.64 kW
- Conditioned rated short-circuit current Iq (EF001444): 0.05 kA
- Rated short-time withstand current lcw (EF007050): 50 kA
- Suitable for fuses (EF006692): NH4a
- Number of poles (EF001391): 3
- With error protection (EF007384): No
- Type of electrical connection of main circuit (EF006819): Screw connection
- Equipped with connectors (EF011696): No
- Suitable for floor mounting (EF007243): No
- Suitable for front mounting (EF007246): Yes
- Suitable for busbar mounting (EF007259): No
- Type of control element (EF006976): Cover grip
More info
▲General specifications
IEC 60947-3
