PFR-W-140 285603 0004365089 EATON ELECTRIC Current transformer for earth-leakage circuit-breaker inner diame..
PFR-W-140
285603
0004365089
EATON - MOELLER
1 Pcs.
Automation > Residual current release for power circuit breaker
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
A current transformer for earth-leakage circuit-breaker acts as a core-balance sensor, wrapping around phase and neutral conductors to detect unbalanced magnetic fields created by ground faults. These robust sensing devices are integral to power distribution monitoring, feeding accurate signals to downstream monitoring relays.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Rated control supply voltage AC 50 Hz (EF003978): 0 V
- Rated control supply voltage AC 60 Hz (EF003979): 0 V
- Rated control supply voltage DC (EF003980): 0 V
- Rated fault current (EF003975): 0 A
- Max. power on-delay time (EF008259): 0 ms
- Delay adjustable (EF001420): No
- Max. rated operation voltage Ue (EF007357): 0 V
More info
▲Delivery program
not UL/CSA approved
incl. screw fixing
Alternative: fixing clip for DIN mounting rail
Design note:
The current transformer diameter must be selected 1.5 times larger than the envelope diameter of the passed through conductor.
