EATON - MOELLER XAD1206 XAD1206 283816 Y7-283816 EATON ELECTRIC Rain protection roof, IP31, for WxD 1200x600mm View larger
Images are for illustrative purposes only. Please refer to data sheet for details

XAD1206 283816 Y7-283816 EATON ELECTRIC Rain protection roof, IP31, for WxD 1200x600mm

XAD1206

283816

Y7-283816

EATON - MOELLER

1 Pcs.

Rain protection roof, IP31, for WxD=1200x600mm XAD1206 Canopy, ventilated with offset screen frame, two piece, including mounting material, steel plate, powder-spray painted, RAL 7035, IP31, width 1200mm, depth 600 mm

Automation > Top-/floor cover element (enclosure/switchgear cabinet)
Enclosures

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Eaton Moeller rain protection roof is an enclosure accessory designed to shield industrial distribution panels and cabinet structures from dripping water and falling debris. This protective top cover installs directly onto compatible modular housing units, helping to maintain internal component ratings by preventing moisture ingress in demanding indoor environments.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Suitable for roof planking: Yes
  • Suitable for bottom planking: Yes
  • Width: 500 mm
  • Height: 85 mm
  • Depth: 1120 mm
  • Suitable for enclosure building width: 1200 mm
  • Suitable for enclosure building depth: 600 mm
  • Material: Steel
  • Surface finishing: Powder coated
  • Colour: Grey
  • RAL-number: 7035
  • With de-aeration: Yes
  • Suitable for outdoor set-up: No
  • With cable entry: No

More info

▲

General specifications

Product Name
Eaton xEnergy Main LV switchgear
Catalog Number
283816
Model Code
XAD1206
EAN
4015082838164
Product Length/Depth
1120 mm
Product Height
85 mm
Product Width
500 mm
Product Weight
11.08 kg
Compliances
RoHS conform

Product specifications

Fitted with:
De-aeration
Surface finishing
Powder coating
Color
Gray
RAL-number
7035
Suitable for enclosure building length/depth
600 mm
Suitable for enclosure building width
1200 mm
Material
Steel
Suitable for
Roof planking
Bottom planking
