CMUC230/25-22 137403 Y7-137403 EATON ELECTRIC Installation contactor, 230 VAC/DC, 2N/C+2N/O, 25A
CMUC230/25-22
137403
Y7-137403
EATON - MOELLER
1 Pcs.
Automation > Installation contactor for distribution board
Modular Switchgear – Others and Accessories
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An Eaton Moeller installation contactor (model CMUC230/25-22) is an electromechanical switching device utilized for remotely controlling lighting circuits, heating systems, and small motors within distribution boards. These components manage electrical loads securely in commercial and residential electrical installations.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Rated operating voltage (EF001435): 440 V
- Rated operation current (EF007679): 25 A
- Rated excitation voltage (EF008409): 195.5 V
- Voltage type (operating voltage) (EF005294): AC/DC
- Voltage type (excitation voltage) (EF005293): AC/DC
- Number of contacts as normally open contact (EF008256): 2
- Number of contacts as normally closed contact (EF008255): 2
- Max. incandescent lamp load (EF004952): 3000 W
- Max. load fluorescent lamp (EF004971): 1360 VA
- Max. load fluorescent lamp (Duo circuit) (EF004972): 2552 VA
- Max. load fluorescent lamp (parallel compensated) (EF004973): 1360 VA
- Slider for hand switch (EF005240): No
- Width in number of modular spacings (EF002950): 2
- Built-in depth (EF000218): 69.5 mm
- Additional equipment possible (EF008148): Yes
- With day/night function (EF021124): No
More info
▲General specifications
Product specifications
Hum-free
