> EATON - MOELLER > 236016
EATON - MOELLER PKNM-6/1N/C/001-MW PKNM-6/1N/C/001-MW 236016 EATON ELECTRIC RCD/MCB combination switch, 6A, 10mA, miniature circuit-br. type C .. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

PKNM-6/1N/C/001-MW 236016 EATON ELECTRIC RCD/MCB combination switch, 6A, 10mA, miniature circuit-br. type C ..

PKNM-6/1N/C/001-MW

236016

EATON - MOELLER

1 Pcs.

RCD/MCB combination switch, 6A, 10mA, miniature circuit-br. type C trip characteristic, 1-phase+N, residual current circuit-br. trip characteristic: AC

Automation > Earth leakage circuit breaker

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Design verification as per IEC/EN 61439(Show features)(Hide features)
Technical data for design verification
Rated operational current for specified heat dissipation
 In A 6
Heat dissipation per pole, current-dependent
 Pvid W 0
Equipment heat dissipation, current-dependent
 Pvid W 1.9
Static heat dissipation, non-current-dependent
 Pvs W 0
Heat dissipation capacity
 Pdiss W 0
Operating ambient temperature min.
 °C -25
Operating ambient temperature max.
 °C 40
0
IEC/EN 61439 design verification
10.2 Strength of materials and parts
10.2.2 Corrosion resistance
 Meets the product standard's requirements.
10.2.3.1 Verification of thermal stability of enclosures
 Meets the product standard's requirements.
10.2.3.2 Verification of resistance of insulating materials to normal heat
 Meets the product standard's requirements.
10.2.3.3 Verification of resistance of insulating materials to abnormal heat and fire due to internal electric effects
 Meets the product standard's requirements.
10.2.4 Resistance to ultra-violet (UV) radiation
 Meets the product standard's requirements.
10.2.5 Lifting
 Does not apply, since the entire switchgear needs to be evaluated.
10.2.6 Mechanical impact
 Does not apply, since the entire switchgear needs to be evaluated.
10.2.7 Inscriptions
 Meets the product standard's requirements.
10.3 Degree of protection of ASSEMBLIES
 Does not apply, since the entire switchgear needs to be evaluated.
10.4 Clearances and creepage distances
 Meets the product standard's requirements.
10.5 Protection against electric shock
 Does not apply, since the entire switchgear needs to be evaluated.
10.6 Incorporation of switching devices and components
 Does not apply, since the entire switchgear needs to be evaluated.
10.7 Internal electrical circuits and connections
 Is the panel builder's responsibility.
10.8 Connections for external conductors
 Is the panel builder's responsibility.
10.9 Insulation properties
10.9.2 Power-frequency electric strength
 Is the panel builder's responsibility.
10.9.3 Impulse withstand voltage
 Is the panel builder's responsibility.
10.9.4 Testing of enclosures made of insulating material
 Is the panel builder's responsibility.
10.10 Temperature rise
 The panel builder is responsible for the temperature rise calculation. Eaton will provide heat dissipation data for the devices.
10.11 Short-circuit rating
 Is the panel builder's responsibility. The specifications for the switchgear must be observed.
10.12 Electromagnetic compatibility
 Is the panel builder's responsibility. The specifications for the switchgear must be observed.
10.13 Mechanical function
 The device meets the requirements, provided the information in the instruction leaflet (IL) is observed.
Technical data ETIM 6.0
Circuit breakers and fuses (EG000020) / Earth leakage circuit breaker (EC000905)
Electric engineering, automation, process control engineering / Electrical installation, device / Residual current protection system / MCB/RCCB combination ([email protected] [AFZ810012])
Number of poles (total)
 2
Number of protected poles
 1
Nominal rated voltage
 V 230
Nominal rated current
 A 6
Rated fault current
 A 0.01
Leakage current type
 AC
Current limiting class
 3
Rated short-circuit breaking capacity EN 60898
 kA 10
Rated short-circuit breaking capacity IEC 60947-2
 kA 0
Frequency
 50 Hz
Release characteristic
 C
Concurrently switching N-neutral
 Yes
Over voltage category
 3
Pollution degree
 2
Width in number of modular spacings
 2
Built-in depth
 mm 70
Suitable for flush-mounted installation
 No
Degree of protection (IP)
 IP20
Surge current capacity
 kA 0.25
Voltage type
 AC
Antinuisance tripping version
 No

ETIM for 236016 Circuit breakers and fuses (EC000905)
Feature Name Feature Value
Number of poles (total) (EF008618) 2
Number of protected poles (EF005548) 1
Rated current (EF000227) 6 A
Rated fault current (EF002358) 0.01 A
Leakage current type (EF002560) AC
Current limiting class (EF002568) 3
Surge current capacity (EF002564) 0.25 kA
Voltage type (EF000187) AC
Frequency (EF005455) 50 Hz
Release characteristic (EF000889) C
Concurrently switching neutral conductor (EF005997) Yes
With interlocking device (EF007385) No
Over voltage category (EF002569) 3
Pollution degree (EF002570) 2
Ambient temperature during operating (EF007515) -25 °C
Width in number of modular spacings (EF002950) 2
Built-in depth (EF000218) 70 mm
Anti-nuisance tripping version (EF009497) No
Degree of protection (IP) (EF005474) IP20
