PKNM-20/1N/C/01-MW 236246 EATON ELECTRIC RCD/MCB combination switch, 20A, 100mA, miniature circuit-br. type ..
PKNM-20/1N/C/01-MW
236246
EATON - MOELLER
1 Pcs.
Automation > Earth leakage circuit breaker
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
A combination switch integrates miniature circuit breaker elements with residual current protection, safeguarding circuits against overcurrents and earth leakage risks. This Eaton Moeller PKNM-20/1N/C/01-MW unit is typically installed in distribution panels to maintain system integrity.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Rated operational current for specified heat dissipation: I n
- Heat dissipation per pole, current-dependent: P vid
- Equipment heat dissipation, current-dependent: P vid
- Static heat dissipation, non-current-dependent: P vs
- Heat dissipation capacity: P diss
- Number of poles (total) (EF008618): 2
- Number of protected poles (EF005548): 1
- Rated current (EF000227): 20 A
- Rated fault current (EF002358): 0.1 A
- Leakage current type (EF002560): AC
- Current limiting class (EF002568): 3
- Surge current capacity (EF002564): 0.25 kA
- Voltage type (EF000187): AC
- Frequency (EF005455): 50 Hz
- Release characteristic (EF000889): C
- Concurrently switching neutral conductor (EF005997): Yes
More info
▲Technical data for design verification | |||
Rated operational current for specified heat dissipation | In | A | 20 |
Heat dissipation per pole, current-dependent | Pvid | W | 0 |
Equipment heat dissipation, current-dependent | Pvid | W | 4.7 |
Static heat dissipation, non-current-dependent | Pvs | W | 0 |
Heat dissipation capacity | Pdiss | W | 0 |
Operating ambient temperature min. | °C | -25 | |
Operating ambient temperature max. | °C | 40 | |
| 0 | |||
IEC/EN 61439 design verification | |||
10.2 Strength of materials and parts | |||
10.2.2 Corrosion resistance | Meets the product standard's requirements. | ||
10.2.3.1 Verification of thermal stability of enclosures | Meets the product standard's requirements. | ||
10.2.3.2 Verification of resistance of insulating materials to normal heat | Meets the product standard's requirements. | ||
10.2.3.3 Verification of resistance of insulating materials to abnormal heat and fire due to internal electric effects | Meets the product standard's requirements. | ||
10.2.4 Resistance to ultra-violet (UV) radiation | Meets the product standard's requirements. | ||
10.2.5 Lifting | Does not apply, since the entire switchgear needs to be evaluated. | ||
10.2.6 Mechanical impact | Does not apply, since the entire switchgear needs to be evaluated. | ||
10.2.7 Inscriptions | Meets the product standard's requirements. | ||
10.3 Degree of protection of ASSEMBLIES | Does not apply, since the entire switchgear needs to be evaluated. | ||
10.4 Clearances and creepage distances | Meets the product standard's requirements. | ||
10.5 Protection against electric shock | Does not apply, since the entire switchgear needs to be evaluated. | ||
10.6 Incorporation of switching devices and components | Does not apply, since the entire switchgear needs to be evaluated. | ||
10.7 Internal electrical circuits and connections | Is the panel builder's responsibility. | ||
10.8 Connections for external conductors | Is the panel builder's responsibility. | ||
10.9 Insulation properties | |||
10.9.2 Power-frequency electric strength | Is the panel builder's responsibility. | ||
10.9.3 Impulse withstand voltage | Is the panel builder's responsibility. | ||
10.9.4 Testing of enclosures made of insulating material | Is the panel builder's responsibility. | ||
10.10 Temperature rise | The panel builder is responsible for the temperature rise calculation. Eaton will provide heat dissipation data for the devices. | ||
10.11 Short-circuit rating | Is the panel builder's responsibility. The specifications for the switchgear must be observed. | ||
10.12 Electromagnetic compatibility | Is the panel builder's responsibility. The specifications for the switchgear must be observed. | ||
10.13 Mechanical function | The device meets the requirements, provided the information in the instruction leaflet (IL) is observed. |
| Circuit breakers and fuses (EG000020) / Earth leakage circuit breaker (EC000905) | |||
| Electric engineering, automation, process control engineering / Electrical installation, device / Residual current protection system / MCB/RCCB combination ([email protected] [AFZ810012]) | |||
Number of poles (total) | 2 | ||
Number of protected poles | 1 | ||
Nominal rated voltage | V | 230 | |
Nominal rated current | A | 20 | |
Rated fault current | A | 0.1 | |
Leakage current type | AC | ||
Current limiting class | 3 | ||
Rated short-circuit breaking capacity EN 60898 | kA | 10 | |
Rated short-circuit breaking capacity IEC 60947-2 | kA | 0 | |
Frequency | 50 Hz | ||
Release characteristic | C | ||
Concurrently switching N-neutral | Yes | ||
Over voltage category | 3 | ||
Pollution degree | 2 | ||
Width in number of modular spacings | 2 | ||
Built-in depth | mm | 70 | |
Suitable for flush-mounted installation | No | ||
Degree of protection (IP) | IP20 | ||
Surge current capacity | kA | 0.25 | |
Voltage type | AC | ||
Antinuisance tripping version | No | ||
