EATON - MOELLER IZMX-CRB IZMX-CRB 156670 EATON ELECTRIC Coding device cassette View larger
Images are for illustrative purposes only. Please refer to data sheet for details

IZMX-CRB 156670 EATON ELECTRIC Coding device cassette

IZMX-CRB

156670

EATON - MOELLER

1 Pcs.

Coding device cassette For use in the withdrawable units, ensures that the IZMX power switch or INX load-separation switch provided fits into the right cassette

Automation > Accessories/spare parts for low-voltage switch technology
Circuit Breakers IZM

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

A coding device cassette is used in modular switchgear installations to mechanically prevent incorrect insertion of withdrawable circuit breaker components into incompatible mounting cassettes. This Eaton Moeller IZMX-CRB part ensures correct slot allocation and enhances installation safety in power distribution systems.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Type of accessory/spare part (EF000215): Coding part
  • Accessory (EF013236): No
  • Spare part (EF013237): No

More info

▲
Delivery programme
Accessories
Withdrawable units
Accessories
Coding
The user-defined coding ensures that a cassette can only accommodate the circuit-breaker assigned to it.
For use with
IZMX16…W
INX16…W
IZMX40…W
INX40…W
Design verification as per IEC/EN 61439(Show features)(Hide features)
Technical data for design verification
Operating ambient temperature min.
°C -25
Operating ambient temperature max.
°C 70
Technical data ETIM 6.0
Low-voltage industrial components (EG000017) / Accessories for low-voltage switch technology (EC002498)
Electric engineering, automation, process control engineering / Low-voltage switch technology / Low-voltage switch technology (accessories) / Component for low-voltage switch technology (accessories) ([email protected] [AKN570010])
Type of accessory
Coding part
