+IZMX-SR230AD 123741 EATON ELECTRIC Closing release 220-240 VAC/DC
+IZMX-SR230AD
123741
EATON - MOELLER
1 Pcs.
Automation > Shunt release (for power circuit breaker)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Closing release +IZMX-SR230AD 123741 EATON ELECTRIC Closing release 220-240 VAC/DC functions within electrical switchgear to remotely energize and close heavy-duty air circuit breakers upon receipt of a control signal.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Rated control supply voltage AC 50 Hz (EF003978): 208 V
- Rated control supply voltage AC 60 Hz (EF003979): 208 V
- Rated control supply voltage DC (EF003980): 220 V
- Voltage type for actuating (EF008242): AC/DC
- Type of electric connection (EF003961): Flat plug-in connection
- Number of contacts as normally open contact (EF008256): 0
- Number of contacts as normally closed contact (EF008255): 0
- Number of contacts as change-over contact (EF008257): 0
- Suitable for power circuit breaker (EF005863): Yes
- Suitable for off-load switch (EF001543): Yes
- Suitable for motor safety switch (EF005826): No
- Suitable for overload relay (EF001545): No
More info
▲Delivery program
Please note - the circuit-breaker's switching frequency = 60/h
208 - 250 V DC V
INX16..., INX40...
Suitable for continuous commands (100% DF)
The ON command can only be accepted if the circuit-breaker is OFF and ready to be switched. If, for example, there is a 100% DF signal at the closing release and the circuit-breaker interlock is then removed, the circuit-breaker will not switch ON. However, this can be ensured automatically by connecting it in series with an LCS auxiliary contact.
