NZMB1-AF70-NA 272209 Y7-272209 EATON ELECTRIC Circuit-breaker, 3p, 70A
NZMB1-AF70-NA
272209
Y7-272209
EATON - MOELLER
1 Pcs.
Automation > Power circuit-breaker for trafo/generator/installation protection
Circuit Breakers NZM
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An Eaton Moeller circuit-breaker serves as an essential safety component in electrical distribution, automatically disconnecting power when fault currents exceed safe operational thresholds. These breakers are commonly installed in industrial distribution boards to safeguard machinery and wiring from damage.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Rated permanent current Iu (EF001389): 70 A
- Rated voltage (EF003977): 440 V
- Overload release current setting (EF002336): 70 A
- Adjustment range undelayed short-circuit release (EF007131): 480 A
- Device construction (EF008240): Built-in device fixed built-in technique
- Integrated earth fault protection (EF007296): No
- Type of electrical connection of main circuit (EF006819): Frame clamp
- Suitable for DIN rail (top hat rail) mounting (EF007250): No
- DIN rail (top hat rail) mounting optional (EF008904): Yes
- With switched-off indicator (EF007006): No
- With integrated under voltage release (EF001390): No
- Number of poles (EF001391): 3
- Position of connection for main current circuit (EF006671): Front
- Type of control element (EF006976): Rocker lever
- Complete device with protection unit (EF008906): Yes
- Motor drive integrated (EF006697): No
More info
▲General specifications
Specially designed for North America
CSA (File No. 22086)
UL/CSA
IEC
UL (Category Control Number DIVQ)
IEC 60947-2
CSA (Class No. 1432-01)
UL (File No. E31593)
UL 489
IEC/EN 60947
CSA-C22.2 No. 5-09
CE marking
UL listed
Product specifications
- Branch circuits, feeder circuits
- Use in unearthed supply systems at 440 V
DIN rail (top hat rail) mounting optional
Built-in device fixed built-in technique
Damp heat, cyclic, to IEC 60068-2-30
300 V AC (between the auxiliary contacts)
IP20 (basic degree of protection, in the operating controls area)
160 A (380/400 V AC-1, making and breaking capacity)
IP66 (with door coupling rotary handle)
IP10 (tunnel terminal)
Min. 2 segments of 9 mm x 0.8 mm at box terminal
Current limiting circuit breaker
16 mm² - 18 mm² (2x)
Min. 12 mm x 5 mm direct at switch rear-side connection
Max. 16 mm x 5 mm direct at switch rear-side connection
16 mm² - 95 mm² (1x) at tunnel terminal
6 mm² - 12 mm² (1x) direct at switch rear-side connection
6 mm² - 9 mm² (2x) direct at switch rear-side connection
25 mm² - 70 mm² (1x) at box terminal
4 mm² - 2/0 mm² (1x) direct at switch rear-side connection
4 mm² - 3/0 mm² (1x) at tunnel terminal
