EATON - MOELLER IZM-CS4 IZM-CS4 122879 Y7-122879 EATON ELECTRIC Cell switch contacts, 4C/O View larger
Images are for illustrative purposes only. Please refer to data sheet for details

IZM-CS4 122879 Y7-122879 EATON ELECTRIC Cell switch contacts, 4C/O

IZM-CS4

122879

Y7-122879

EATON - MOELLER

1 Pcs.

Cell switch contacts, 4C/O IZM-CS4 Signalling Contact, Position, 4W Auxiliary switch, Position signalling switches, For use with: IZM20, 32, 40, 63…W, IN20, 32, 40, 63…W

Automation > Auxiliary contact block
Circuit Breakers IZM

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

The IZM-CS4 122879 Y7-122879 EATON ELECTRIC Cell switch contacts, 4C/O provide electrical position feedback for draw-out circuit breakers, indicating whether the device is connected, tested, or disconnected from its cradle.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Rated operation current Ie at AC-15, 230 V (EF001385): None A

More info

▲
Cell switch contacts, 4C/O
Eaton Catalog No.
2A10702G01
Auxiliary switch, Position signalling switches, For use with: IZM20, 32, 40, 63…W, IN20, 32, 40, 63…W
[

Delivery program

Accessories
Withdrawable units
Accessories
Position signalling switches
4 changeover contacts:
Card without mounting plate
For use with
IZM20, 32, 40, 63…W
IN20, 32, 40, 63…W
,

Design verification as per IEC/EN 61439

Operating ambient temperature min.
-25 °C
Operating ambient temperature max.
+70 °C
]

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
