C22-WRK-K20 132531 EATON ELECTRIC C22-WRK-K20
C22-WRK-K20
132531
EATON - MOELLER
1 Pcs.
Automation > Selector switch, complete
Auxiliary Control and Signalling Elements
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The Eaton Moeller C22-WRK-K20 is a toggle-actuated selector switch built for reliable manual control on industrial machinery. Toggle selector switches provide tactile feedback and clear positioning for operators managing system functions on control panels.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Number of switch positions (EF000231): 2
- Type of control element (EF006976): Toggle
- Suitable for lighting (EF001142): No
- With light source (EF005905): No
- Colour button (EF000190): Black
- Hole diameter (EF000079): 22.5 mm
- Width opening (EF004565): 0 mm
- Height opening (EF004778): 0 mm
- Switching function latching (EF007447): Yes
- Spring-return (EF001407): No
- Degree of protection (IP) (EF005474): IP65
- Degree of protection (NEMA) (EF011959): 3R
- Supply voltage (EF004127): 0 V
- Number of contacts as normally open contact (EF008256): 2
- Number of contacts as normally closed contact (EF008255): 0
- Number of contacts as change-over contact (EF008257): 0
More info
▲Delivery program
= spring-return]
60°Technical data
VDE 0660
Damp heat, cyclic, to IEC 60068-2-30
