EATON - MOELLER C22-PVT60P-K02 C22-PVT60P-K02 121613 Y7-121613 EATON ELECTRIC Emergency-stop, 60mm, pull/turn release, 2N/C, black View larger
Images are for illustrative purposes only. Please refer to data sheet for details

C22-PVT60P-K02 121613 Y7-121613 EATON ELECTRIC Emergency-stop, 60mm, pull/turn release, 2N/C, black

C22-PVT60P-K02

121613

Y7-121613

EATON - MOELLER

1 Pcs.

Emergency-stop, 60mm, pull/turn release, 2N/C, black C22-PVT60P-K02 Eaton Moeller® series C22 Emergency-stop, Palm-tree shape, 60 mm, Turn-to-release function, 2 NC, Screw connection Emergency-stop, Product range: RMQ Compact, Complete unit, Design: Palm-tree shape, Diameter: 60 mm, Illumination: Non-illuminated, Turn-to-release function, Connection type: Screw connection, Description: Tamper-proof according to ISO 13850/EN 418, Color Mushroom head: Red, Color Base: yellow, Red mushroom head (RAL 3000), Degree of Protection: IP66, IP67, IP69K, Connection to SmartWire-DT: no, Contacts N/C = Normally closed: 2 NC, Contacts Notes: = safety function, by positive opening to IEC/EN 60947-5-1, Actuator travel and actuation force as per DIN EN 60947-5-1, K.5.4.1: mm 4.65, Maximum travel: mm 5.7 , Minimum force for positive opening: N 30, Function: Turn-to-release function, Standards: IEC/EN 60947-5-5, VDE 0660

Automation > Emergency stop complete
Auxiliary Control and Signalling Elements

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

General specifications

Product Name
Eaton Moeller® series C22 Emergency-stop button
Catalog Number
121613
Model Code
C22-PVT60P-K02
EAN
4015081194315
Product Length/Depth
95 mm
Product Height
60 mm
Product Width
60 mm
Product Weight
0.062 kg
Certifications
CE

Features & Functions

Unlocking method
Turn-release

General

Degree of protection
IP67/IP69K
NEMA 4X, 13
Mounting method
Built-in
Mounting position
As required
Opening diameter
22.5 mm

Electrical rating

Rated insulation voltage (Ui)
250 V

Contacts

Number of contacts (normally closed contacts)
2
Number of contacts (normally open contacts)
0

ETIM for 121613 Low-voltage industrial controls and switchgear (EC002034)
Feature Name Feature Value
Unlocking method (EF001403) Turn-release
Number of contacts as normally closed contact (EF008255) 2
Number of contacts as normally open contact (EF008256) 0
Degree of protection (IP) (EF005474) IP67/IP69K
Degree of protection (NEMA) (EF011959) 4X, 13
Mounting method (EF000003) Built-in
With lighting (EF003829) No
Supply voltage lamp (EF006522) 0 V
Hole diameter (EF000079) 22.5 mm
Connection type auxiliary circuit (EF006820) Screw connection
Diameter cap (EF001423) 60 mm

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
