> EATON - MOELLER > Bussmann Series Low Voltage fuses and accessories > 450NHG2B
EATON - MOELLER NH FUSE 450A 500V GG SIZE 2 NH FUSE 450A 500V GG SIZE 2 450NHG2B EATON ELECTRIC Fuse-link, 10x38 mm, 2A, gG View larger
Images are for illustrative purposes only. Please refer to data sheet for details

NH FUSE 450A 500V GG SIZE 2 450NHG2B EATON ELECTRIC Fuse-link, 10x38 mm, 2A, gG

NH FUSE 450A 500V GG SIZE 2

450NHG2B

450NHG2B

EATON - MOELLER

3 Pcs.

Fuse-link, 10x38 mm, 2A, gG NH FUSE 450A 500V GG SIZE 2 Fuse-link, low voltage, 450 A, AC 500 V, NH2, gL/gG, IEC, dual indicator Fuse, Fuse-link, low voltage, 450 A, AC 500 V, NH2, gL/gG, IEC, dual indicator, square body with knife blade contacts, live gripping lugs, IEC 60269-2 fuse system A, DIN 43620, VDE 0636-2, Breaking Capacity 120 kA, Optional accessories fuse-holder SD2-D and SD2-S

Automation > Low Voltage HRC fuse
Bussmann Series Low Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

General specifications

Product Name
Eaton Bussmann series low voltage NH Fuse
Catalog Number
450NHG2B
Model Code
NH FUSE 450A 500V GG SIZE 2
EAN
5027590480710
UPC
051712683654
Product Length/Depth
150 mm
Product Height
71 mm
Product Width
53 mm
Product Weight
659 g
Compliances
CE Marked
RoHS Compliant
Certifications
IEC 60269-1
IEC 60269-2
DIN 43620

Product specifications

Type
Fuse
Application
Amperage Rating
450 A
Fitted with:
Metal gripping lugs
Fuse size
NH2
Current type
AC
Breaking capacity
120 kA
Rated switching capacity
120 kA
Rated voltage AC
500 V
Class
Class gG/gL
Fuse type
Square body with knife blade contact
Accessory/spare part type
SDL-2 Solid link
FEH- Fuse extraction handle
SD12-SK Shroud kit
SD12-PB 2-phase barriers and 2 ganging links
TD2-IP20 Triple pole protection kit
Utilization category
gL/gG (cable protection/equipment protection)
Interrupt rating
120 kAIC
Fuse indicator
Combination fuse status indicator
Insulated metal gripping lugs (IMGL)
No
Watt losses
31 W
Connection
Blade end
Construction
NH2
Construction size
NH2
Fuse shape
Square body
Knife blade contacts
Voltage type
AC
Suitable for
SD2-D Single pole NH Fuse base
TD2-D Tripe pole NH Fuse base
Microswitch 170H0235
Microswitch 170H0236
EBH Size 00 to 4 Horizontal fuse switch-disconnectors
Material
Ceramic body
Quantity
3
Voltage rating
500 V
Rated switching capacity AC
120 kA

ETIM for 450NHG2B Circuit breakers and fuses (EC000055)
Feature Name Feature Value
Fuse construction type according to IEC 60269 (EF015865) NH2
Voltage type (EF000187) AC
Rated current (EF000227) 450 A
Rated voltage AC (EF007682) 500 V
Rated switching capacity AC (EF017698) 120 kA
Utilization category according to IEC 60269 (EF002572) gG (cable protection/equipment protection)
Type of fuse status indicator (EF004473) Combination fuse status indicator
Insulated metal gripping lugs (IMGL) (EF012538) No
Power loss at rated current (EF012389) 31 W
