AZ-4-C80 211802 Y7-211802 EATON ELECTRIC Miniature circuit breaker (MCB), 80A, 1p, C-Char
AZ-4-C80
AZ-4-C80
Y7-211802
EATON - MOELLER
1 unit
Automation > Miniature circuit breaker (MCB)
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Protection against electrical faults in high-capacity distribution networks is provided by the Eaton Moeller AZ-4-C80 miniature circuit breaker. Industrial installations rely on these devices to automatically interrupt excessive currents, thereby safeguarding infrastructure and connected assets.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Built-in depth: 75 mm
- Release characteristic: C
- Number of poles (total): 4
- Number of protected poles: 4
- Rated current: 80 A
- Rated voltage: 400 V
- Rated insulation voltage Ui: 440 V
- Rated impulse withstand voltage Uimp: 4 kV
- Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V: 0 kA
- Voltage type: AC
- Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V: 0 kA
- Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V: 20 kA
- Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V: 20 kA
- Frequency: 50 Hz
- Current limiting class: 3
- Flush-mounted installation: No
More info
▲General specifications
EN45545-2
IEC 61373
Delivery programme
- AZ
- Miniature circuit breaker
Technical data - electrical
Technical data - mechanical
IP40 (when fitted)
Design verification as per IEC/EN 61439 - technical data
Design verification as per IEC/EN 61439
Additional information
Additional equipment possible
Miniature circuit breaker
