AZ-4-C100 211807 Y7-211807 EATON ELECTRIC Miniature circuit breaker (MCB), 100A, 1p, C-Char
AZ-4-C100
AZ-4-C100
Y7-211807
EATON - MOELLER
1 unit
Automation > Miniature circuit breaker (MCB)
Modular Switchgear – Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An Eaton Moeller miniature circuit breaker (MCB) is designed to protect high-amperage electrical circuits from sustained overloads and damaging short circuits in heavy industrial switchgear. This 100A four-pole unit ensures reliable circuit isolation and protects distribution networks from fault conditions. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Built-in depth: 75 mm
- Release characteristic: C
- Number of poles (total): 4
- Number of protected poles: 4
- Rated current: 100 A
- Rated voltage: 400 V
- Rated insulation voltage Ui: 440 V
- Rated impulse withstand voltage Uimp: 4 kV
- Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V: 0 kA
- Voltage type: AC
- Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V: 0 kA
- Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V: 20 kA
- Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V: 20 kA
- Frequency: 50 Hz
- Current limiting class: 3
- Flush-mounted installation: No
