EATON - MOELLER +IZM-AS22 +IZM-AS22 122758 EATON ELECTRIC Auxiliary switch, ON-OFF, 2N/O+2N/C View larger
Images are for illustrative purposes only. Please refer to data sheet for details

+IZM-AS22 122758 EATON ELECTRIC Auxiliary switch, ON-OFF, 2N/O+2N/C

+IZM-AS22

122758

EATON - MOELLER

1 Pcs.

Auxiliary switch, ON-OFF, 2N/O+2N/C Standard auxiliary switch, for ON/OFF annunciation

Automation > Auxiliary contact block

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Auxiliary switch, ON-OFF, 2N/O+2N/C
Standard auxiliary switch, for ON/OFF annunciation
[

Delivery program

Accessories
Auxiliary contact
Accessories
Standard auxiliary switch for On-Off signaling
Additionally 2 NO / NC contacts
For use with
IZM20, 32, 40, 63…
IN20, 32, 40, 63…
,

Technical data

Rated breaking capacity
Inductive load250 V AC
10 A
Inductive load125 V DC
0.5 A
Inductive load250 V DC
0.25 A
,

Design verification as per IEC/EN 61439

Operating ambient temperature min.
-25 °C
Operating ambient temperature max.
+70 °C
]

ETIM for 122758 Low-voltage industrial controls and switchgear (EC000041)
Feature Name Feature Value
Number of contacts as change-over contact (EF008257)
Number of contacts as normally open contact (EF008256)
Number of contacts as normally closed contact (EF008255)
Number of fault-signal switches (EF007613)
Rated operation current Ie at AC-15, 230 V (EF001385) None A
Type of electric connection (EF003961)
Model (EF000010)
Mounting method (EF000003)
Lamp holder (EF000048)
