> EATON - MOELLER > Bussmann Series Low Voltage fuses and accessories > 80NHG2B690
EATON - MOELLER 80NHG2B-690 80NHG2B-690 NH FUSE 80AMP 690V gG SIZE 2 DUAL IND EATON ELECTRIC Fuse-link, LV, 100 A, AC 690V, NH1, gL/gG, .. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

80NHG2B-690 NH FUSE 80AMP 690V gG SIZE 2 DUAL IND EATON ELECTRIC Fuse-link, LV, 100 A, AC 690V, NH1, gL/gG, ..

80NHG2B-690

80NHG2B690

NH FUSE 80AMP 690V gG SIZE 2 DUAL IND

EATON - MOELLER

1 Pcs.

Fuse-link, LV, 100 A, AC 690V, NH1, gL/gG, IEC, dual indicator, insulated gripping lugs NH FUSE 80A 690V gG SIZE 2 NH FUSE 80A 690V gG SIZE 2 - Fuse-link, LV, 80 A, AC 690 V, NH2, gL/gG, IEC, dual indicator, live gripping lugs Fuse, Fuse-link, low voltage, 80 A, AC 690 V, NH2, gL/gG, IEC, dual (combination) indicator system, square-body with knife blade contacts, live gripping lugs, IEC 60269-2 fuse system A, DIN 43620, VDE 0636-2, Breaking Capacity 120 kA

Automation > Low Voltage HRC fuse
Bussmann Series Low Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Fuse-link, LV, 80 A, AC 690 V, NH2, gL/gG, IEC, dual indicator, live gripping lugs
Fuse, Fuse-link, low voltage, 80 A, AC 690 V, NH2, gL/gG, IEC, dual (combination) indicator system, square-body with knife blade contacts, live gripping lugs, IEC 60269-2 fuse system A, DIN 43620, VDE 0636-2, Breaking Capacity 120 kA

Delivery program

Product range
Fuse
Basic function
Fuse-link
Field of application
low voltage
Rated current [I]
80 A
Rated voltage
AC 690 V
Construction size
NH2
Utilization category
gL/gG
Status indicator
dual (combination) indicator system
Description
live gripping lugs
Breaking Capacity
120 kA
Standard/Approval
IEC
Shape
square body with knife blade contacts
Standards/Regulations
IEC 60269-2 fuse system A
DIN 43620
VDE 0636-2

Technical data ETIM 7.0

Circuit breakers and fuses (EG000020) / Low Voltage HRC fuse (EC000055)
Electric engineering, automation, process control engineering / Electrical installation, device / Safety fuse inserts / Low-Voltage HRC fuse ([email protected] [AFZ800015])
Construction size
NH2
Rated current
80 A
Rated voltage
690 V
Voltage type
AC
Rated switching capacity
120 kA
Utilization category
gL/gG (cable protection/equipment protection)
Type of fuse status indicator
Combination fuse status indicator
Insulated metal gripping lugs (IMGL)
No

ETIM for 80NHG2B-690 Circuit breakers and fuses (EC000055)
Feature Name Feature Value
Fuse construction type according to IEC 60269 (EF015865) NH2
Rated current (EF000227) 80 A
Utilization category according to IEC 60269 (EF002572) gG (cable protection/equipment protection)
Type of fuse status indicator (EF004473) Combination fuse status indicator
Insulated metal gripping lugs (IMGL) (EF012538) No
