> EATON - MOELLER > Bussmann Series Medium Voltage fuses and accessories > 72CAV2
EATON - MOELLER 7.2KV 2A 8" FUSE 7.2KV 2A 8" FUSE 7.2CAV2 7-2CAV2 EATON ELECTRIC VT fuse-link, medium voltage, 2 A, AC 7.2 kV, 220 x 41.3 mm,.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

7.2KV 2A 8" FUSE 7.2CAV2 7-2CAV2 EATON ELECTRIC VT fuse-link, medium voltage, 2 A, AC 7.2 kV, 220 x 41.3 mm,..

7.2KV 2A 8" FUSE

72CAV2

7-2CAV2

EATON - MOELLER

5 Pcs.

VT fuse-link, medium voltage, 2 A, AC 7.2 kV, 220 x 41.3 mm, back-up, BS, IEC 7.2KV 2A 8" FUSE Fuse, VT fuse-link, medium voltage, 2 A, AC 7.2 kV, 220 x 41.3 mm, back-up, BS, IEC, cylindrical, voltage and auxiliary transformers, BS2692-1, IEC 60282-1, Breaking Capacity 40 kA

Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
VT fuse-link, medium voltage, 2 A, AC 7.2 kV, 220 x 41.3 mm, back-up, BS, IEC
Fuse, VT fuse-link, medium voltage, 2 A, AC 7.2 kV, 220 x 41.3 mm, back-up, BS, IEC, cylindrical, voltage and auxiliary transformers, BS2692-1, IEC 60282-1, Breaking Capacity 40 kA

General specifications
Product name
Eaton Bussmann series medium auxiliary fuse
Part no.
7.2CAV2
EAN
5027590487986
Product Length/Depth
220 millimetre
Product height
41.3 millimetre
Product width
41.3 millimetre
Product weight
700 gram
Compliances
Contact Manufacturer
Certifications
IEC
BS
Product Tradename
None
Product Type
Medium voltage auxiliary fuse
Product Sub Type
None
Electrical data
Amperage Rating
2 A
Voltage rating
7.2 kV
Breaking capacity
40 kA
Performance Cat According To IEC 60282-1
Back-up
Rated frequency - min
62 Hz
Class
Class back-up
Resistance
0.89 ohms
Product specifications
Application
Protection of auxiliary transformers
Fuse indicator
Non Indicating
Fuse size
220 x 41.3 mm
Standard
IEC

ETIM for 7.2CAV2 Circuit breakers and fuses (EC003507)
Feature Name Feature Value
Rated current (EF000227) 2 A
Rated voltage (EF000228) 7.2 kV
Voltage type (EF000187) AC
Rated frequency (EF001663) 62 Hz
Breaking capacity (EF005617) 40 kA
Utilization category according to IEC 60269 (EF002572) Other
Application (EF000041) Auxiliary transformer protection
Length (EF001438) 220 mm
Performance category according to IEC 60282-1 (EF012539) Back-up
With striker (EF008175) No
Standard (EF009322) IEC
Release characteristic (EF000889) Other
Installation technique (EF001474) Air

Product Datasheet
