EATON - MOELLER 7.2KV 160A AIR FUSE 1121 7.2KV 160A AIR FUSE 1121 7.2BFGHZ160 7-2BFGHZ160 EATON ELECTRIC cartridge fuse Air, MT, 160 A, AC 7.2 kV, BS.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

7.2KV 160A AIR FUSE 1121 7.2BFGHZ160 7-2BFGHZ160 EATON ELECTRIC cartridge fuse Air, MT, 160 A, AC 7.2 kV, BS..

7.2KV 160A AIR FUSE 1121

72BFGHZ160

7-2BFGHZ160

EATON - MOELLER

3 Pcs.

cartridge fuse Air, MT, 160 A, AC 7.2 kV, BS, 76 x 461 mm, back-up, BS, with striker Air fuse cartridge, MT, 160 A, AC 7.2 kV, BS, 76 x 461 mm, back-up, BS, with striker 7.2BFGHZ160 - Air fuse-link, medium voltage, 160 A, AC 7.2 kV, BS, 76 x 461 mm, back-up, BS, with striker Fuse, Air fuse-link, medium voltage, 160 A, AC 7.2 kV, BS, 76 x 461 mm, back-up, BS, with striker, cylindrical with special tag, protection of primary side transformers, BS2692-1, Breaking Capacity 40 kA

Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Utilized in heavy electrical infrastructure, the Eaton Moeller 7.2KV 160A AIR FUSE 1121 functions as a cartridge fuse for medium voltage transformer protection. These units interrupt high fault currents to ensure grid stability and prevent damage to substations. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Rated current (EF000227): 160 A
  • Rated voltage (EF000228): 7.2 kV
  • Voltage type (EF000187): AC
  • Rated frequency (EF001663): 50 Hz
  • Breaking capacity (EF005617): 40 kA
  • Application (EF000041): Primary side transformer protection
  • Length (EF001438): 356.2 mm
  • Diameter (EF000551): 76.2 mm
  • Performance category according to IEC 60282-1 (EF012539): Back-up
  • With striker (EF008175): Yes
  • Standard (EF009322): British Standard
  • Installation technique (EF001474): Air

More info

▲
Air fuse-link, medium voltage, 160 A, AC 7.2 kV, BS, 76 x 461 mm, back-up, BS, with striker
Fuse, Air fuse-link, medium voltage, 160 A, AC 7.2 kV, BS, 76 x 461 mm, back-up, BS, with striker, cylindrical with special tag, protection of primary side transformers, BS2692-1, Breaking Capacity 40 kA

Delivery program

Product range
Fuse
Basic function
Air fuse-link
Field of application
medium voltage
Rated current [I]
160 A
Rated voltage
AC 7.2 kV
Construction size
BS
Size
76 x 461 mm
Utilization category
back-up
Status indicator
with striker
Breaking Capacity
40 kA
usable for size/applications
protection of primary side transformers
Standard/Approval
BS
Shape
cylindrical with special tag
Standards/Regulations
BS2692-1

Technical data ETIM 7.0

Circuit breakers and fuses (EG000020) / Medium-/high voltage fuse (EC003507)
Rated current
160 A
Rated voltage
7.2 kV
Voltage type
AC
Rated frequency
50 - 50 Hz
Breaking capacity
40 kA
Utilization category
Other
Application
Primary side transformer protection
Length
461 mm
Diameter
76 mm
Performance category according to IEC 60282-1
Back-up
With striker
Yes
Standard
British Standard
Release characteristic
Other
Installation technique
Air
