> EATON - MOELLER > Bussmann Series Medium Voltage fuses and accessories > 72TFLSJ125
EATON - MOELLER 7.2KV 125Amp 3" 'J' DIN Fuse 7.2KV 125Amp 3" 'J' DIN Fuse 7.2TFLSJ125 7-2TFLSJ125 EATON ELECTRIC cartridge fuse, MT, 125 A, AC 7.2 kV, 3".. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

7.2KV 125Amp 3" 'J' DIN Fuse 7.2TFLSJ125 7-2TFLSJ125 EATON ELECTRIC cartridge fuse, MT, 125 A, AC 7.2 kV, 3"..

7.2KV 125Amp 3" 'J' DIN Fuse

72TFLSJ125

7-2TFLSJ125

EATON - MOELLER

3 Pcs.

cartridge fuse, MT, 125 A, AC 7.2 kV, 3", 76 x 292 mm, Back-up, DIN, with striker 7.2KV 125Amp 3" 'J' DIN Fuse 7.2KV 125Amp 3" 'J' DIN Fuse - Fuse-link, medium voltage, 125 A, AC 7.2 kV, 40 kA, 3", 76 x 292 mm, back-up, DIN, with striker Fuse, Fuse-link, medium voltage, 125 A, AC 7.2 kV, 3z, 76 x 292 mm, Back-up, DIN, with striker, transformer protection, indoor or outdoor use, DIN 43625, VDE 0670 Part 4, VDE 0670 Part 402, IEC 60282-1, Breaking Capacity 40 kA

Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Fuse-link, medium voltage, 125 A, AC 7.2 kV, 40 kA, 3", 76 x 292 mm, back-up, DIN, with striker
Fuse, Fuse-link, medium voltage, 125 A, AC 7.2 kV, 3", 76 x 292 mm, Back-up, DIN, with striker, transformer protection, indoor or outdoor use, DIN 43625, VDE 0670 Part 4, VDE 0670 Part 402, IEC 60282-1, Breaking Capacity 40 kA

Delivery program

Product range
Fuse
Basic function
Fuse-link
Field of application
medium voltage
Rated current [I]
125 A
Rated voltage
AC 7.2 kV
Construction size
3"
Size
76 x 292 mm
Utilization category
back-up
Status indicator
with striker
Breaking Capacity
40 kA
usable for size/applications
transformer protection
indoor or outdoor use
Standard/Approval
DIN
Standards/Regulations
DIN 43625
VDE 0670-4
VDE 0670-402
IEC 60282-1

Technical data ETIM 7.0

Circuit breakers and fuses (EG000020) / Medium-/high voltage fuse (EC003507)
Rated current
25 A
Rated voltage
7.2 kV
Voltage type
AC
Rated frequency
50 - 50 Hz
Breaking capacity
40 kA
Utilization category
Other
Application
Primary side transformer protection
Length
292 mm
Diameter
76 mm
Performance category according to IEC 60282-1
Back-up
With striker
Yes
Standard
DIN
Release characteristic
Other
Installation technique
Air

ETIM for 7.2TFLSJ125 Circuit breakers and fuses (EC003507)
Feature Name Feature Value
Rated current (EF000227) 125 A
Rated voltage (EF000228) 7.2 kV
Voltage type (EF000187) AC
Rated frequency (EF001663) 50 Hz
Breaking capacity (EF005617) 40 kA
Utilization category according to IEC 60269 (EF002572) Other
Application (EF000041) Primary side transformer protection
Length (EF001438) 292 mm
Diameter (EF000551) 76 mm
Performance category according to IEC 60282-1 (EF012539) Back-up
With striker (EF008175) Yes
Standard (EF009322) DIN
Release characteristic (EF000889) Other
Installation technique (EF001474) Air
