EATON - MOELLER 7.2WFNHA25 7.2WFNHA25 7.2KV 25AMP 3" MOTORSTART DCR 2474 EATON ELECTRIC Motor fuse-link, medium voltage, 25 A, AC 7.2 k.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

7.2WFNHA25 7.2KV 25AMP 3" MOTORSTART DCR 2474 EATON ELECTRIC Motor fuse-link, medium voltage, 25 A, AC 7.2 k..

7.2WFNHA25

72WFNHA25

7.2KV 25AMP 3" MOTORSTART DCR 2474

EATON - MOELLER

3 Pcs.

Motor fuse-link, medium voltage, 25 A, AC 7.2 kV, 76 x 403 mm, back-up, BS, with striker, no tags 7.2KV 25AMP 3" MOTORSTART DCR 2474 7.2KV 25A 3" MOTOR START FUSE - Motor fuse-link, medium voltage, 25 A, AC 7.2 kV, 76 x 403 mm, back-up, BS, with striker, no tags Fuse, Motor fuse-link, medium voltage, 25 A, AC 7.2 kV, 76 x 403 mm, back-up, BS, with striker, cylindrical, motor protection, BS2692-1, IEC 60282-1, Breaking Capacity 40 kA

Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Protecting medium-voltage motor circuits against overloads and short circuits, the Eaton Moeller 7.2WFNHA25 motor fuse-link is designed for demanding industrial environments. Specialized motor fuses interrupt fault currents to prevent overheating and premature wear in large electrical drives. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Rated current (EF000227): 25 A
  • Rated voltage (EF000228): 7.2 kV
  • Voltage type (EF000187): AC
  • Rated frequency (EF001663): 50 Hz
  • Breaking capacity (EF005617): 0.04 kA
  • Length (EF001438): 530 mm
  • Performance category according to IEC 60282-1 (EF012539): Back-up
  • With striker (EF008175): Yes
  • Standard (EF009322): British Standard
  • Installation technique (EF001474): Air

More info

▲
Motor fuse-link, medium voltage, 25 A, AC 7.2 kV, 76 x 403 mm, back-up, BS, with striker, no tags
Fuse, Motor fuse-link, medium voltage, 25 A, AC 7.2 kV, 76 x 403 mm, back-up, BS, with striker, cylindrical, motor protection, BS2692-1, IEC 60282-1, Breaking Capacity 40 kA

Delivery program

Product range
Fuse
Basic function
Motor fuse-link
Field of application
medium voltage
Rated current [I]
25 A
Rated voltage
AC 7.2 kV
Size
76 x 403 mm
Utilization category
back-up
Status indicator
with striker
Breaking Capacity
40 kA
usable for size/applications
motor protection
Standard/Approval
BS
Shape
cylindrical
Standards/Regulations
BS2692-1
IEC 60282-1

Technical data ETIM 7.0

Circuit breakers and fuses (EG000020) / Medium-/high voltage fuse (EC003507)
Rated current
25 A
Rated voltage
7.2 kV
Voltage type
AC
Rated frequency
50 - 50 Hz
Breaking capacity
40 kA
Utilization category
Other
Application
Motor protection
Length
530 mm
Diameter
76 mm
Performance category according to IEC 60282-1
Back-up
With striker
Yes
Standard
British Standard
Release characteristic
Other
Installation technique
Air
