7.2KV 50Amp 2" DIN Sealed Fuse 7.2TDLSJ50 7-2TDLSJ50 EATON ELECTRIC Fuse-link, medium voltage, 50 A, AC 7.2 ..
7.2KV 50Amp 2" DIN Sealed Fuse
72TDLSJ50
7-2TDLSJ50
EATON - MOELLER
3 Pcs.
Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Protection against high fault currents in medium-voltage circuits is provided by the Eaton Moeller 7.2KV 50Amp 2' DIN Sealed Fuse 7.2TDLSJ50. Units of this type act as critical safeguards for distribution transformers, interrupting abnormal current surges to preserve system integrity. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Rated current (EF000227): 50 A
- Rated voltage (EF000228): 7.2 kV
- Voltage type (EF000187): AC
- Rated frequency (EF001663): 50 Hz
- Breaking capacity (EF005617): 40 kA
- Application (EF000041): Primary side transformer protection
- Length (EF001438): 292 mm
- Diameter (EF000551): 51 mm
- Performance category according to IEC 60282-1 (EF012539): Back-up
- With striker (EF008175): Yes
- Standard (EF009322): DIN
- Installation technique (EF001474): Air
More info
▲Delivery program
indoor or outdoor use
VDE 0670-4
VDE 0670-402
IEC 60282-1
