5.5KV 9R AIR M/S FUSE 5.5VKNHA9R 5-5VKNHA9R EATON ELECTRIC Motor fuse-link, medium voltage, 200 A, AC 5.5 kV..
5.5KV 9R AIR M/S FUSE
55VKNHA9R
5-5VKNHA9R
EATON - MOELLER
1 Pcs.
Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The Eaton Moeller 5.5KV 9R AIR M/S FUSE is a medium voltage motor fuse-link engineered to protect heavy industrial motor drives from damaging overloads. Fuses of this classification are standard in robust electrical panels to ensure safety during fault events. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Rated current (EF000227): 200 A
- Rated voltage (EF000228): 5.5 kV
- Voltage type (EF000187): AC
- Rated frequency (EF001663): 60 Hz
- Breaking capacity (EF005617): 60 kA
- Application (EF000041): Motor protection
- Length (EF001438): 403 mm
- Diameter (EF000551): 76 mm
- Performance category according to IEC 60282-1 (EF012539): Back-up
- With striker (EF008175): Yes
- Standard (EF009322): IEEE
- Release characteristic (EF000889): R
- Installation technique (EF001474): Air
