5.5KV 2X9R 3" M/S FUSE 5.5VKNHK18R 5-5VKNHK18R EATON ELECTRIC Motor fuse-link, medium voltage, 390 A, AC 5.5..
5.5KV 2X9R 3" M/S FUSE
55VKNHK18R
5-5VKNHK18R
EATON - MOELLER
1 Pcs.
Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The Eaton Moeller 5.5KV 2X9R 3" M/S FUSE (5.5VKNHK18R) acts as a specialized medium-voltage motor fuse-link. Industrial motor protection devices are implemented to handle heavy inrush profiles while interrupting dangerous short-circuit faults. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Rated current (EF000227): 390 A
- Rated voltage (EF000228): 5.5 kV
- Voltage type (EF000187): AC
- Rated frequency (EF001663): 60 Hz
- Breaking capacity (EF005617): 0.06 kA
- Length (EF001438): 403 mm
- Performance category according to IEC 60282-1 (EF012539): Back-up
- With striker (EF008175): Yes
- Standard (EF009322): IEEE
- Release characteristic (EF000889): R
- Installation technique (EF001474): Air
