EATON - MOELLER 5.5KV 2X12R 3" M/S  TWIN FUSE 5.5KV 2X12R 3" M/S TWIN FUSE 5.5VKNHK24R 5-5VKNHK24R EATON ELECTRIC Motor fuse-link, medium voltage, 450 A, .. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

5.5KV 2X12R 3" M/S TWIN FUSE 5.5VKNHK24R 5-5VKNHK24R EATON ELECTRIC Motor fuse-link, medium voltage, 450 A, ..

5.5KV 2X12R 3" M/S TWIN FUSE

55VKNHK24R

5-5VKNHK24R

EATON - MOELLER

1 Pcs.

Motor fuse-link, medium voltage, 450 A, AC 5.5 kV, 76 x 403 mm, back-up, US, 24R, with striker Motor cartridge fuse, MT, 450 A, AC 5.5 kV, 76 x 403 mm, back-up, US, 24R, with striker Fuse, Motor fuse-link, medium voltage, 450 A, AC 5.5 kV, 76 x 403 mm, back-up, US, 24R, with striker, cylindrical, dual-barrel, motor protection, ANSI C37-46, Breaking Capacity 60 kA

Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

The 5.5KV 2X12R 3" M/S TWIN FUSE by Eaton Moeller serves as a heavy-duty motor fuse-link for medium-voltage applications. Twin-fuse configurations are typically utilized in high-demand industrial motor controllers to handle large startup currents while ensuring rapid fault clearing.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Rated current (EF000227): 450 A
  • Rated voltage (EF000228): 5.5 kV
  • Voltage type (EF000187): AC
  • Rated frequency (EF001663): 60 Hz
  • Breaking capacity (EF005617): 0.06 kA
  • Length (EF001438): 403 mm
  • Performance category according to IEC 60282-1 (EF012539): Back-up
  • With striker (EF008175): Yes
  • Standard (EF009322): IEEE
  • Release characteristic (EF000889): R
  • Installation technique (EF001474): Air

More info

▲
Motor fuse-link, medium voltage, 450 A, AC 5.5 kV, 76 x 403 mm, back-up, US, 24R, with striker
Fuse, Motor fuse-link, medium voltage, 450 A, AC 5.5 kV, 76 x 403 mm, back-up, US, 24R, with striker, cylindrical, dual-barrel, motor protection, ANSI C37-46, Breaking Capacity 60 kA

Delivery program

Product range
Fuse
Basic function
Motor fuse-link
Field of application
medium voltage
Rated current [I]
450 A
Rated voltage
AC 5.5 kV
Size
76 x 403 mm
Utilization category
back-up
Status indicator
with striker
Description
dual-barrel
Breaking Capacity
60 kA
usable for size/applications
motor protection
Release characteristic [class]
24R
Standard/Approval
US
Shape
cylindrical
Standards/Regulations
ANSI C37-46

Technical data ETIM 7.0

Circuit breakers and fuses (EG000020) / Medium-/high voltage fuse (EC003507)
Rated current
450 A
Rated voltage
5.5 kV
Voltage type
AC
Rated frequency
60 - 60 Hz
Breaking capacity
60 kA
Utilization category
Other
Application
Motor protection
Length
403 mm
Diameter
76 mm
Performance category according to IEC 60282-1
Back-up
With striker
Yes
Standard
IEEE
Release characteristic
R
Installation technique
Air

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
