EATON - MOELLER 5.5KV 12R FUSE 5.5KV 12R FUSE 5.5VKNHA12R 5-5VKNHA12R EATON ELECTRIC Fuse, Air fuse-link, medium voltage, 10 A, AC 12 kV, 5.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

5.5KV 12R FUSE 5.5VKNHA12R 5-5VKNHA12R EATON ELECTRIC Fuse, Air fuse-link, medium voltage, 10 A, AC 12 kV, 5..

5.5KV 12R FUSE

55VKNHA12R

5-5VKNHA12R

EATON - MOELLER

1 Pcs.

Fuse, Air fuse-link, medium voltage, 10 A, AC 12 kV, 51 x 359 mm, back-up, BS, with striker, style 36 tags 5.5KV 12R FUSE 5.5VKNHA12R - Motor fuse-link, medium voltage, 230 A, AC 5.5 kV, 76 x 403 mm, back-up, US, 12R, with striker Fuse, Motor fuse-link, medium voltage, 230 A, AC 5.5 kV, 76 x 403 mm, back-up, US, 12R, with striker, cylindrical, motor protection, ANSI C37-46, Breaking Capacity 60 kA

Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Motor fuse-link, medium voltage, 230 A, AC 5.5 kV, 76 x 403 mm, back-up, US, 12R, with striker
Fuse, Motor fuse-link, medium voltage, 230 A, AC 5.5 kV, 76 x 403 mm, back-up, US, 12R, with striker, cylindrical, motor protection, ANSI C37-46, Breaking Capacity 60 kA

General specifications
Product name
Eaton Bussmann series medium voltage fuse
Part no.
5.5VKNHA12R
EAN
5027590048736
Product Length/Depth
403 millimetre
Product height
78 millimetre
Product width
78 millimetre
Product weight
4244 gram
Compliances
Contact factory
Product Tradename
None
Product Type
Medium voltage fuse
Product Sub Type
None
Electrical data
Amperage Rating
230 A
Voltage rating
5.5 kV
Breaking capacity
60 kA
Performance Cat According To IEC 60282-1
Back-up
Rated frequency - min
60 Hz
Class
Class back-up
Product specifications
Application
Motor protection
Fuse indicator
With Striker
Fuse size
76 x 276 mm
Standard
IEEE
Compatible fuse clip
Used with
A3354730 Nickel-plated copper fuse clip

Technical data ETIM 9.0

Circuit breakers and fuses (EG000020) / Medium/high voltage fuse (EC003507)
Electric engineering, automation, process control engineering / Electrical installation, device / Miniature circuit breaker system (MCB) / Medium-/high voltage fuse (ecl@ss13-27-14-19-11 [AGA534005])
Rated current
230 A
Rated voltage
5.5 kV
Voltage type
AC
Rated frequency
60 - 60 Hz
Breaking capacity
60 kA
Utilization category
Other
Application
Motor protection
Length
403 mm
Diameter
76 mm
Performance category according to IEC 60282-1
Back-up
With striker
Yes
Standard
IEEE
Release characteristic
R
Installation technique
Air

ETIM for 5.5VKNHA12R Circuit breakers and fuses (EC003507)
Feature Name Feature Value
Rated current (EF000227) 230 A
Rated voltage (EF000228) 5.5 kV
Voltage type (EF000187) AC
Rated frequency (EF001663) 60 Hz
Breaking capacity (EF005617) 60 kA
Utilization category according to IEC 60269 (EF002572) Other
Application (EF000041) Motor protection
Length (EF001438) 403 mm
Diameter (EF000551) 76 mm
Performance category according to IEC 60282-1 (EF012539) Back-up
With striker (EF008175) Yes
Standard (EF009322) IEEE
Release characteristic (EF000889) R
Installation technique (EF001474) Air
