EATON - MOELLER 500V 500A NH4 FUSE gG 500V 500A NH4 FUSE gG 500NHG4G 0001664093 EATON ELECTRIC Fuse-link, LV, 1000 A, AC 500 V, NH4, gL/gG, IEC, s.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

500V 500A NH4 FUSE gG 500NHG4G 0001664093 EATON ELECTRIC Fuse-link, LV, 1000 A, AC 500 V, NH4, gL/gG, IEC, s..

500V 500A NH4 FUSE gG

500NHG4G

500NHG4G

EATON - MOELLER

1 Pcs.

Fuse-link, LV, 1000 A, AC 500 V, NH4, gL/gG, IEC, single indicator, live gripping lugs fuse cartridge, BT 500 A, AC 500 V, NH4, gL/gG, IEC, single indicator, metal terminals 500V 500A NH4 FUSE gG - Fuse-link, low voltage, 500 A, AC 500 V, 120 kA, NH4, gL/gG, IEC, single indicator, live gripping lugs Fuse, Fuse-link, low voltage, 500 A, AC 500 V, NH4, gL/gG, IEC, single (top) indicator system, square-body with slotted blade contacts, live gripping lugs, IEC 60269-2 fuse system A, DIN 43620, VDE 0636-2, Breaking Capacity 120 kA

Automation > Low Voltage HRC fuse
Bussmann Series Low Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
EL-Nummer (Norway)
1664090
Fuse-link, low voltage, 500 A, AC 500 V, 120 kA, NH4, gL/gG, IEC, single indicator, live gripping lugs
Fuse, Fuse-link, low voltage, 500 A, AC 500 V, NH4, gL/gG, IEC, single (top) indicator system, square-body with slotted blade contacts, live gripping lugs, IEC 60269-2 fuse system A, DIN 43620, VDE 0636-2, Breaking Capacity 120 kA

Delivery program

Product range
Fuse
Basic function
Fuse-link
Field of application
low voltage
Rated current [I]
500 A
Rated voltage
AC 500 V
Construction size
NH4
Utilization category
gL/gG
Status indicator
single indicator
Description
live gripping lugs
Breaking Capacity
120 kA
Standard/Approval
IEC
Shape
square body with slotted blade contacts
Standards/Regulations
IEC 60269-2 fuse system A
DIN 43620
VDE 0636-2

Technical data ETIM 7.0

Circuit breakers and fuses (EG000020) / Low Voltage HRC fuse (EC000055)
Electric engineering, automation, process control engineering / Electrical installation, device / Safety fuse inserts / Low-Voltage HRC fuse ([email protected] [AFZ800015])
Construction size
NH4
Rated current
500 A
Rated voltage
500 V
Voltage type
AC
Rated switching capacity
120 kA
Utilization category
gL/gG (cable protection/equipment protection)
Type of fuse status indicator
Top fuse status indicator
Insulated metal gripping lugs (IMGL)
No

ETIM for 500NHG4G Circuit breakers and fuses (EC000055)
Feature Name Feature Value
Fuse construction type according to IEC 60269 (EF015865) NH4
Voltage type (EF000187) AC
Rated current (EF000227) 500 A
Rated voltage AC (EF007682) 500 V
Rated switching capacity AC (EF017698) 120 kA
Utilization category according to IEC 60269 (EF002572) gG (cable protection/equipment protection)
Type of fuse status indicator (EF004473) Top fuse status indicator
Insulated metal gripping lugs (IMGL) (EF012538) No
Power loss at rated current (EF012389) 37 W
